AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X100-20

The AirTAC SEJ Adjustable Cylinder SEJ32X100-20 is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 20mm window, so this Ø32mm unit covers an effective stroke of 80–100mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke100 mm
  • Adjust window20 mm
  • Effective stroke80–100 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$67.22 $74.72Save 10% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X100-20

The AirTAC SEJ32X100-20 is a double-acting, double-rod ISO 15552 profile cylinder featuring an adjustable stroke. A rod exits both ends, ensuring the annulus area is identical in both directions.

You can mechanically dial the retract end up to 20 mm via a stop screw on the back rod, yielding an effective stroke range of 80-100 mm. This allows precise end-position tuning directly on the machine without changing hardware. The extruded aluminum barrel omits external tie rods, and field-adjustable air cushions at both ends decelerate the load near the stroke ends.

Airtac SEJ Adjustable Cylinder SEJ32X100-20 Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X100-20
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke100 mm
Adjustment window20 mm (80–100 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 20mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X100-20

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Nominal stroke length in mm.
-20Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X100-20 Is Used

tune

Gripper Commissioning

Dial in the exact 80-100 mm jaw closure distance on an assembly fixture, using the 345 N both-way force to grip precisely without overshooting.

swap_horiz

Packaging Changeover

Adjust the retract stroke on the fly when switching box sizes, using the back-rod stop screw to set new mechanical ends for the 32 mm bore.

precision_manufacturing

Trial Spot Welding

Test electrode positioning on a 32 mm bore actuator, fine-tuning the end stop within the 20 mm window to find the optimal contact point.

Is the Airtac SEJ Adjustable Cylinder SEJ32X100-20 the Right Cylinder?

Confirm the 20 mm adjustment window covers your required end-position variance. If you need less force, the next bore down is unavailable in this ISO 15552 range, but if you need more, stepping up to the 40 mm bore yields 528 N both ways at 0.5 MPa. If your application never requires stroke changes, a fixed-stroke SED cylinder is sufficient.

For sizing, this 32 mm bore provides 345 N at 0.5 MPa and 483 N at 0.7 MPa. Because it is a plain double-acting cylinder, it will not hold position on air loss; the adjustable cushion and stop screw only set the mechanical end and decelerate the load, so add an external rod lock for fail-safe holding. Ensure your ISO 15552 replacement matches the 100 mm stroke, 20 mm window, PT1/8 port, and mounting subset (Basic, FA, LB, TC, FTC, TCM1, TCM2).

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (20mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 20mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X100-20 FAQ

A stop screw on the rear rod lets you mechanically shorten the retract stroke by up to 20 mm. The effective stroke range is 80-100 mm, which you set and lock on the machine to fine-tune the end position.

Because the rod exits both ends, force is equal in both directions. This 32 mm bore generates 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
