AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X100-20SH

The AirTAC SEJ Adjustable Cylinder SEJ32X100-20SH is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 20mm window, so this Ø32mm unit covers an effective stroke of 80–100mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke100 mm
  • Adjust window20 mm
  • Effective stroke80–100 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$76.06 $83.56Save 8% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X100-20SH

The AirTAC SEJ32X100-20SH is a double-acting, double-rod ISO 15552 profile cylinder featuring a 20mm adjustable stroke window. A rod exits both ends, yielding identical annulus areas for equal force in both directions at 345 N each way at 0.5 MPa. You can dial the retract end from 80mm to 100mm via a back-rod stop screw to fine-tune the machine end position.

Built for high-temperature service, the Viton (FKM) seal extends the operating range up to 150 C. The integrated magnet supports CMSE reed and DMSE electronic sensors for position feedback. Adjustable air cushions at both ends decelerate the motion near stroke end, and the extruded aluminum barrel provides ISO 15552 dimensional interchangeability without external tie rods.

Airtac SEJ Adjustable Cylinder SEJ32X100-20SH Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X100-20SH
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke100 mm
Adjustment window20 mm (80–100 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 20mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X100-20SH

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Nominal stroke length in mm.
-20Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X100-20SH Is Used

tune

Packaging Stop Dial-In

Dial the retract stroke from 80 to 100mm to precisely set the tucking arm position on a packaging line, using the 345 N both-way force to consistently fold material.

settings

Hot-End Valve Seat

Leverage the 150 C Viton seal and 483 N equal both-way force to actuate a hot process valve seat, fine-tuning the 20mm closure distance during commissioning.

swap_horiz

Changeover Positioning

Adjust the end stop without disassembling hardware to shift a 32mm bore pick-and-place head between part heights, relying on the equal push and pull dynamics.

Is the Airtac SEJ Adjustable Cylinder SEJ32X100-20SH the Right Cylinder?

Confirm the 20mm adjustment window covers your required 80-100mm end position. If you need less force, the smaller bore is not available in this series, so you would look outside the SEJ range. If you need more force, stepping up to the 40mm bore provides 528 N both ways at 0.5 MPa, while the 50mm bore yields 825 N. If your stroke is fixed and never changes, a standard SED double-rod cylinder is sufficient. For direct ISO 15552 replacement, match the 32mm bore, 100mm nominal stroke, PT1/8 port, and your mounting choice from Basic, FA, LB, TC, FTC, TCM1, or TCM2. Remember that the air cushion and stop screw only set the mechanical end and decelerate motion; a plain SEJ does not hold position on air loss, so use an external rod lock for fail-safe holding.

AirtacDistr lists every SEJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sej32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (20mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 20mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X100-20SH FAQ

A stop screw on the back rod mechanically shortens the retract stroke over a 20mm window. You can dial the effective stroke from 80mm up to 100mm, then lock the screw in place to maintain the exact end position.

Because it is a double-rod cylinder, the force is identical in both directions: 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa. The Viton FKM seal extends the operating temperature range up to 150 C.
