AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X100-30S

The AirTAC SEJ Adjustable Cylinder SEJ32X100-30S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 30mm window, so this Ø32mm unit covers an effective stroke of 70–100mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke100 mm
  • Adjust window30 mm
  • Effective stroke70–100 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$70.01 $77.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X100-30S

The AirTAC SEJ32X100-30S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 30 mm adjustable stroke window. You can dial the retract end-position from 70 mm up to the nominal 100 mm, letting you fine-tune the machine stop on the floor without swapping hardware.

This 32 mm bore unit includes a standard magnet for CMSE reed or DMSE electronic position sensing. The extruded aluminum barrel contains no external tie rods, and adjustable air cushions at both ends absorb kinetic energy near stroke completion. A mechanical stop screw on the rear rod sets your effective range, which you lock down after commissioning.

Airtac SEJ Adjustable Cylinder SEJ32X100-30S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X100-30S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke100 mm
Adjustment window30 mm (70–100 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 30mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X100-30S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Nominal stroke length in mm.
-30Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X100-30S Is Used

tune

Pick-and-Place Height Calibration

Dial the 30 mm retract window to perfectly match varying PCB thicknesses on a pick-and-place head, utilizing the 345 N both-way force for reliable component placement.

swap_horiz

Packaging Changeover

Adjust the effective stroke from 70 to 100 mm during format changeovers on a packaging line to accommodate different carton depths without changing cylinder hardware.

precision_manufacturing

Small-Part Pressing

Fine-tune the pressing depth of lightweight bearings or pins, relying on the equal 483 N extend and retract force at 0.7 MPa to prevent over-travel.

Is the Airtac SEJ Adjustable Cylinder SEJ32X100-30S the Right Cylinder?

Verify the 30 mm adjustment window covers your required end-position variance. If you need less force, stepping down is not an option as 32 mm is the smallest ISO 15552 bore, delivering 345 N both ways at 0.5 MPa. If your application requires more thrust, the next bore up is 40 mm, which provides 528 N both ways at 0.5 MPa. If you do not need variable stroke positioning, a fixed-stroke SED double-rod cylinder provides the same symmetric force in a shorter overall length.

This cylinder does not hold position upon air loss; the adjustable cushion and stop screw only set the mechanical end and decelerate the load, so specify an external rod lock for fail-safe holding. When replacing an ISO 15552 cylinder, match the 32 mm bore, 100 mm nominal stroke, PT1/8 port, and your mounting choice from Basic, FA, LB, TC, FTC, TCM1, or TCM2.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (30mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 30mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X100-30S FAQ

A stop screw on the rear rod lets you mechanically shorten the retract stroke by up to 30 mm. The effective stroke range is 70 to 100 mm, which you set on the machine and lock into place.

Because it is a double-rod cylinder, the force is identical in both directions: 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
