AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X100-40S

The AirTAC SEJ Adjustable Cylinder SEJ32X100-40S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 40mm window, so this Ø32mm unit covers an effective stroke of 60–100mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke100 mm
  • Adjust window40 mm
  • Effective stroke60–100 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$70.01 $77.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X100-40S

The AirTAC SEJ32X100-40S is a double-acting, double-rod ISO 15552 profile cylinder. A rod exits both ends, yielding identical annulus areas so output force is equal in both directions at 345 N each way at 0.5 MPa. A stop screw on the back rod lets you mechanically dial the retract stroke up to 40 mm, providing an effective 60 to 100 mm stroke range without changing hardware.

This 32 mm bore unit features a PT1/8 port, a 12 mm rod with an M10x1.25 thread, and includes a magnet for CMSE or DMSE sensors. Field-adjustable air cushions at both ends manage deceleration near the stroke limits. The mounting set omits FB, CA, CB, and CR brackets, supporting Basic, FA, LB, TC, FTC, TCM1, and TCM2 attachments.

Airtac SEJ Adjustable Cylinder SEJ32X100-40S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X100-40S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke100 mm
Adjustment window40 mm (60–100 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 40mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X100-40S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Nominal stroke length in mm.
-40Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X100-40S Is Used

tune

Packaging Stopper Calibration

Dial the 40 mm retract window to fine-tune the exact 60-100 mm stopping position for varying carton sizes on a packaging line, using the 345 N both-way force to push and pull reliably.

swap_horiz

Assembly Changeover

Adjust the mechanical end position on the machine during product family changeovers, matching new part heights without swapping out the entire cylinder hardware.

precision_manufacturing

Trial Positioning Jig

Use the equal push and pull forces during prototype commissioning to test optimal clamping distances before locking the back-rod stop screw into a final fixed position.

Is the Airtac SEJ Adjustable Cylinder SEJ32X100-40S the Right Cylinder?

Verify the 40 mm adjustment window covers your required end-position range. If you need less force, the next bore down is not available in this series, but if you need more, the 40 mm bore provides 528 N both ways at 0.5 MPa. If your application never requires stroke changes, a fixed-stroke SED cylinder is sufficient. This plain SEJ does not hold position on air loss; the stop screw and air cushions only set the mechanical end and decelerate, so use an external rod lock for fail-safe holding. When replacing an ISO 15552 cylinder, match the 32 mm bore, 100 mm stroke, PT port, and mounting bracket.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (40mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 40mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X100-40S FAQ

The stop screw on the back rod provides a 40 mm adjustment window. You can mechanically dial the retract end from 60 mm up to the nominal 100 mm stroke, allowing precise end-position tuning on the machine.

Because it is a double-rod cylinder, the force is identical in both directions. It provides 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
