AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X100-50

The AirTAC SEJ Adjustable Cylinder SEJ32X100-50 is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 50mm window, so this Ø32mm unit covers an effective stroke of 50–100mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke100 mm
  • Adjust window50 mm
  • Effective stroke50–100 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$67.22 $74.72Save 10% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X100-50

The AirTAC SEJ32X100-50 is a double-acting, double-rod ISO 15552 profile cylinder. A rod exits both ends, yielding identical annulus areas and an equal force of 345 N in both directions at 0.5 MPa. A stop screw on the back rod lets you mechanically dial the retract stroke over a 50 mm window, giving an effective stroke range of 50 to 100 mm.

This aluminum extrusion cylinder omits external tie rods and features field-adjustable air cushions at both ends to decelerate loads near the end of travel. This SKU has no magnet, so position sensing is not available without hardware changes. Mounting options include Basic, FA, LB, TC, FTC, TCM1, and TCM2.

Airtac SEJ Adjustable Cylinder SEJ32X100-50 Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X100-50
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke100 mm
Adjustment window50 mm (50–100 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 50mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X100-50

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Nominal stroke length in mm.
-50Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X100-50 Is Used

precision_manufacturing

Pick-and-Place Tuning

Dial in the 50 to 100 mm retract stroke on an electronics pick-and-place head to match varying PCB heights without swapping hardware.

straighten

Bending Stop Calibration

Use the 345 N both-way force and 50 mm stop-screw window to precisely set and fine-tune the contact point on a light-duty wire bending fixture.

swap_horiz

Changeover Positioning

Adjust the mechanical end position during packaging line changeovers to accommodate different carton depths on the fly.

Is the Airtac SEJ Adjustable Cylinder SEJ32X100-50 the Right Cylinder?

Verify that the 50 mm adjustment window covers your required end-position range. If you need less fine-tuning, a fixed-stroke SED32 or standard SE32 may suffice. For sizing, stepping down is not possible as 32 mm is the smallest bore. Stepping up to the 40 mm bore provides 528 N at 0.5 MPa if your load exceeds the 32 mm output. Remember that the adjustable cushion and stop screw only set the mechanical end and decelerate the load; a plain SEJ does not hold position on air loss. For fail-safe holding, use an external rod lock or a BSED series cylinder. When replacing an ISO 15552 unit, match the 100 mm nominal stroke, 50 mm window, PT1/8 port, and mounting type.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (50mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 50mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X100-50 FAQ

The retract stroke can be dialed in over a 50 mm window using the back-rod stop screw. The effective stroke range is 50 to 100 mm. Lock the screw after setting your desired end position.

Because the rod exits both ends, the force is identical in both directions: 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
