AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X100-50S

The AirTAC SEJ Adjustable Cylinder SEJ32X100-50S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 50mm window, so this Ø32mm unit covers an effective stroke of 50–100mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke100 mm
  • Adjust window50 mm
  • Effective stroke50–100 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$70.01 $77.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X100-50S

The AirTAC SEJ32X100-50S is a double-acting, double-rod ISO 15552 profile cylinder with a 50mm adjustable stroke window, letting you dial the retract end from 50mm up to 100mm. A rod exits both ends, yielding identical annulus areas so output force is equal in both directions at 345 N each way at 0.5 MPa.

It features a PT1/8 port, a 12mm rod, and an -S magnet for position sensing. The extruded aluminum barrel has no external tie rods, and field-adjustable air cushions at both ends decelerate the load near stroke end. A stop screw on the back rod sets the exact mechanical end; lock it after positioning to secure the precise end-point on your machine.

Airtac SEJ Adjustable Cylinder SEJ32X100-50S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X100-50S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke100 mm
Adjustment window50 mm (50–100 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 50mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X100-50S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Nominal stroke length in mm.
-50Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X100-50S Is Used

precision_manufacturing

Precision Stop Grinding

Dial in the exact 50-100mm retract position for a grinding fixture, leveraging the 345N both-way force to push and pull the workhead into the wheel.

swap_horiz

Multi-Height Changeover

Adjust the retract end on the fly to accommodate 50mm to 100mm varying part heights on a packaging line without swapping out cylinder hardware.

science

Trial Positioning Jig

Use the back-rod stop screw to fine-tune the end position during R&D testing of a new assembly process, locking it once the optimal 75mm stroke is found.

Is the Airtac SEJ Adjustable Cylinder SEJ32X100-50S the Right Cylinder?

This 32mm bore model provides 345 N both ways at 0.5 MPa. If your application needs less force, there is no smaller SEJ bore, so you must regulate pressure down. If you need more force, step up to the 40mm bore, which delivers 528 N both ways at 0.5 MPa. The 50mm adjustment window is ideal if your machine changeover requires hitting variable part heights between 50mm and 100mm; if you only need a single fixed 100mm end-point, a standard SED double-rod cylinder is sufficient.

For ISO 15552 replacement matching, verify the 100mm stroke, 50mm window, PT1/8 port, and required mounting subset (Basic, FA, LB, TC, FTC, TCM1, or TCM2). The -S magnet works with CMSE reed and DMSE electronic sensors. Remember that the adjustable air cushion and stop screw only decelerate the load and set the mechanical end; a plain SEJ does not hold position on air loss, so use a BSED or external rod lock for fail-safe holding.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (50mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 50mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X100-50S FAQ

The adjustment window is 50mm, meaning the effective retract stroke can be dialed from 50mm up to the nominal 100mm. Because it is a double-rod design, force is equal both ways: 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.

Yes, it is an ISO 15552 / VDMA 24562 profile cylinder, meaning it is dimensionally interchangeable per ISO 15552 standards. It uses an extruded aluminum barrel without external tie rods and includes a PT1/8 port and a 12mm rod.
