AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X100-50SN

The AirTAC SEJ Adjustable Cylinder SEJ32X100-50SN is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 50mm window, so this Ø32mm unit covers an effective stroke of 50–100mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke100 mm
  • Adjust window50 mm
  • Effective stroke50–100 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$70.01 $77.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X100-50SN

The AirTAC SEJ32X100-50SN is a double-acting, double-rod ISO 15552 profile cylinder. A rod exits both ends, yielding identical annulus areas so output force is equal in both directions. You get 345 N each way at 0.5 MPa and 483 N at 0.7 MPa.

This unit features a 50mm adjustable stroke window via a stop screw on the back rod, allowing you to dial the retract end from 50 to 100mm. The extruded aluminum barrel omits external tie rods, and field-adjustable air cushions at both ends decelerate the piston near stroke end.

Airtac SEJ Adjustable Cylinder SEJ32X100-50SN Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X100-50SN
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke100 mm
Adjustment window50 mm (50–100 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 50mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X100-50SN

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Nominal stroke length in mm.
-50Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X100-50SN Is Used

tune

Press Stroke Calibration

Dial in the exact 50-100mm clamping depth on a small pneumatic press, using the 345N both-way force to seat delicate electronics without crushing the housing.

swap_horiz

Packaging Changeover

Adjust the retract stop on the fly when switching box sizes on a packaging conveyor, avoiding hardware swaps while maintaining precise end-positioning.

precision_manufacturing

Component Insertion

Fine-tune the insertion depth of a 12mm rod into an assembly fixture, locking the back-rod stop screw once the perfect mating depth is found.

Is the Airtac SEJ Adjustable Cylinder SEJ32X100-50SN the Right Cylinder?

This 50mm adjustment window is ideal for fine-tuning end positions during machine commissioning. If you need less force, the next bore down is unavailable in this series, but if you need more power, stepping up to a 40mm bore yields 528 N both ways at 0.5 MPa. If your stroke never changes, a fixed-stroke SED saves complexity. The air cushion decelerates motion but does not hold position on air loss; use an external rod lock for fail-safe holding. For ISO 15552 replacements, match the 32mm bore, 100mm stroke, PT1/8 port, and mounting subset (Basic, FA, LB, TC, FTC, TCM1, TCM2).

AirtacDistr lists every SEJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sej32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (50mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 50mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X100-50SN FAQ

A stop screw on the back rod lets you mechanically shorten the retract stroke over a 50mm window. You can set the effective stroke anywhere from 50mm up to the full 100mm nominal length, then lock it in place.

Because it is a double-rod cylinder, force is identical in both directions: 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
