AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X100-75S

The AirTAC SEJ Adjustable Cylinder SEJ32X100-75S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 75mm window, so this Ø32mm unit covers an effective stroke of 25–100mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke100 mm
  • Adjust window75 mm
  • Effective stroke25–100 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$70.01 $77.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X100-75S

The AirTAC SEJ32X100-75S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 75mm adjustable stroke window. A rear stop screw lets you dial the retract end from 25mm up to the 100mm nominal stroke, eliminating the need to swap hardware for machine commissioning or part changeovers. Because a rod exits both ends, the annulus area is identical in both directions, delivering an equal force of 345 N each way at 0.5 MPa.

This 32mm bore unit integrates a magnet for CMSE reed or DMSE electronic sensors. It uses field-adjustable air cushions at both ends to manage deceleration over the 27mm cushion length. The extruded aluminum barrel is dimensionally interchangeable per ISO 15552, and the rear rod can support a cam or flag while helping guide against rotation.

Airtac SEJ Adjustable Cylinder SEJ32X100-75S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X100-75S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke100 mm
Adjustment window75 mm (25–100 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 75mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X100-75S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Nominal stroke length in mm.
-75Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X100-75S Is Used

tune

Packaging Conveyor Changeover

Dial the retract stroke from 25 to 100mm to accommodate different carton heights on a packaging line, using the equal 345N both-way force to push and pull flap folders without swapping cylinders.

precision_manufacturing

PCB Drill Z-Axis Trial

Fine-tune the precise end-stop during PCB drilling commissioning, leveraging the 75mm adjustment window to find the exact depth before locking the back-rod stop screw.

swap_horiz

Pick-and-Place Variable Stop

Adjust the retract position on the fly for a pick-and-place gantry handling varied component sizes, relying on the M10x1.25 rod thread and stable double-rod guidance to resist side load.

Is the Airtac SEJ Adjustable Cylinder SEJ32X100-75S the Right Cylinder?

Confirm the 75mm adjustment window covers your required end-position range; this single unit effectively replaces multiple fixed-stroke cylinders. If you need less force, stepping down is not an option from 32mm, but if your application requires more thrust, the next bore up is 40mm, which provides 528 N both ways at 0.5 MPa. Conversely, if a fixed end position is sufficient and you do not need variable stops, a standard SED double-rod cylinder provides a simpler setup.

When replacing an ISO 15552 cylinder, match the 32mm bore, 100mm stroke, PT1/8 port, and your required mounting style from the SEJ set (Basic, FA, LB, TC, FTC, TCM1, TCM2). Note that the adjustable air cushion only decelerates the load near stroke end; it does not hold position on air loss. For fail-safe holding, specify an external rod lock.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (75mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 75mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X100-75S FAQ

A mechanical stop screw on the rear rod lets you shorten the retract stroke by up to 75mm. The effective stroke range is 25mm to 100mm. You set the exact end position on the machine, then lock the screw.

Because it is a double-rod cylinder, the force is identical in both directions. It delivers 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
