AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X125-40S

The AirTAC SEJ Adjustable Cylinder SEJ32X125-40S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 40mm window, so this Ø32mm unit covers an effective stroke of 85–125mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke125 mm
  • Adjust window40 mm
  • Effective stroke85–125 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$73.01 $80.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X125-40S

The AirTAC SEJ32X125-40S is a double-acting, double-rod ISO 15552 profile cylinder. A rod exits both ends, yielding identical annulus areas and equal force in both directions—about 345 N each way at 0.5 MPa. A magnet is fitted for CMSE or DMSE sensors.

The retract end features a mechanical stop screw, letting you dial the stroke down by up to 40 mm. This gives an effective stroke range of 85-125 mm, perfect for fine-tuning a precise end position during machine commissioning without swapping hardware. It uses a PT1/8 port and a Ø12 mm rod.

Airtac SEJ Adjustable Cylinder SEJ32X125-40S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X125-40S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke125 mm
Adjustment window40 mm (85–125 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 40mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X125-40S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×125Nominal stroke length in mm.
-40Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X125-40S Is Used

precision_manufacturing

Pick-and-Place Height Tuning

Dial the 40 mm retract window to perfectly match varying part heights on a pick-and-place head, using the 345 N both-way force to lift and lower reliably.

settings

Machine Commissioning

Fine-tune the 85-125 mm effective end position during machine setup, locking the back-rod stop screw exactly where the tooling meets the workpiece.

swap_horiz

Product Changeover

Quickly adapt a packaging line to a new carton size by adjusting the retract stroke up to 40 mm, avoiding the need to physically swap out the cylinder.

Is the Airtac SEJ Adjustable Cylinder SEJ32X125-40S the Right Cylinder?

This 32 mm bore provides 345 N (0.5 MPa) of equal both-way force. If your load is lighter, there is no smaller SEJ bore; if you need more force, step up to the 40 mm bore for 528 N. If you do not need on-the-fly stroke adjustment, a fixed-stroke SED cylinder is simpler. The 40 mm window covers a broad 85-125 mm range. Note: a plain SEJ does not hold position on air loss; the stop screw only sets the mechanical end. For fail-safe holding, use an external rod lock. It is dimensionally interchangeable per ISO 15552.

AirtacDistr lists every SEJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sej32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (40mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 40mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X125-40S FAQ

A stop screw on the back rod lets you mechanically shorten the retract stroke by up to 40 mm. The effective stroke range is 85-125 mm. You dial it in on the machine and lock it, avoiding hardware changes.

Because it is a double-rod cylinder, the force is identical in both directions: 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
