AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X125-50SFA

The AirTAC SEJ Adjustable Cylinder SEJ32X125-50SFA is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 50mm window, so this Ø32mm unit covers an effective stroke of 75–125mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke125 mm
  • Adjust window50 mm
  • Effective stroke75–125 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$79.06 $86.56Save 8% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X125-50SFA

The AirTAC SEJ32X125-50SFA is a double-acting, double-rod ISO 15552 profile cylinder with a 50mm adjustable stroke window. A rear stop screw lets you dial the retract end from 75mm up to 125mm, perfect for fine-tuning a machine end position during commissioning.

This unit includes an S magnet for CMSE or DMSE sensors and an FA front mounting bracket. It uses adjustable air cushions at both ends to decelerate near stroke ends, operating at 30-800 mm/s via a PT1/8 port. The stop screw sets the mechanical end; it is not a fail-safe brake, so add an external rod lock for position holding on air loss.

Airtac SEJ Adjustable Cylinder SEJ32X125-50SFA Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X125-50SFA
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke125 mm
Adjustment window50 mm (75–125 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 50mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X125-50SFA

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×125Nominal stroke length in mm.
-50Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X125-50SFA Is Used

precision_manufacturing

Fixture Depth Calibration

Dial in the exact 75-125mm clamping depth on machining fixtures using the rear stop screw, leveraging the 483N both-way force to secure light metal components.

swap_horiz

Multi-Part Changeover

Quickly adjust the retract stroke to accommodate different part heights on a conveyor line without swapping out the entire cylinder hardware.

tune

Sensor Flag Positioning

Use the extending back rod to carry a cam for DMSE electronic sensors, sliding the 50mm adjustment window to hit the exact trigger point for a packaging machine.

Is the Airtac SEJ Adjustable Cylinder SEJ32X125-50SFA the Right Cylinder?

Verify the 50mm adjustment window covers your required end-position range. If you need less fine-tuning, a fixed-stroke SED might suffice. For sizing, the next bore down is not standard, but stepping up to a 40mm bore raises the both-way force to 528 N at 0.5 MPa. This 32mm bore provides 345 N at 0.5 MPa and 483 N at 0.7 MPa. When replacing an ISO 15552 cylinder, match the 125mm stroke, 50mm window, PT1/8 port, FA mount, and magnet.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (50mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 50mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X125-50SFA FAQ

The 50mm adjustment window lets you mechanically dial the retract stroke from 75mm up to 125mm. You set the exact end position via a stop screw on the back rod and lock it in place.

Because the rod exits both ends, force is equal in both directions: 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
