Airtac SI200 Standard Cylinder SI200X1000H
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X1000H Standard Cylinder Specifications
- Model: SI200X1000H
- Bore size: 200mm
- Stroke: 1000mm
- Operation type: Double-acting
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1-1/2
- Piston speed: 50–800 mm/s
- Mounting type: Basic (MF1) with front/rear threaded mounting holes
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR (nitrile) seals standard, optional polyurethane
- Weight: 43.8 kg (dry, without accessories)
- Dimensions:
- Extended length: 1394mm
- Retracted length: 394mm
- Body diameter: 220mm (with end caps)
- Rod diameter: 50mm
- ISO standard: 15552 compliant
High-capacity industrial cylinder designed for heavy-duty linear motion applications. Features oversized piston bearings for improved lateral load capacity and reduced stick-slip effect during low-speed operation. The chrome-plated piston rod incorporates a multi-layer sealing system with integrated wiper for harsh environments.
- Plastic injection molding machine ejectors
- Steel mill roller positioning systems
- Automotive press line material handling
- Paper mill conveyor gate actuators
- Shipbuilding fixture clamping mechanisms
Installation note:
Requires minimum 2x stroke length clearance for full extension.
Use M20x1.5 mounting bolts with torque limited to 180N·m.
Lubricate rod weekly in high-cycle applications (>500 cycles/day).
- Available with magnetic piston for position sensing
- Optional corrosion-resistant package (CRP) for marine environments
- Custom stroke lengths up to 2000mm with rod support
- High-temperature variant (up to 120℃) with fluorocarbon seals
| Property | Property Value |
|---|---|
| sku | SI200X1000H |
| Seal Material | FKM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
