This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAIJ100X100-40S, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-40S
The AirTAC SIJ100 Double Rod Adjustable Cylinder SIJ100X100-40S is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø100mm bore and 100mm stroke, G1/2 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAIJ100X100-40S, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ100 mm
- Stroke100 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- StatusDiscontinued → SAIJ100X100-40S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-40S
The AirTAC SIJ100X100-40S is a discontinued double-acting double-rod ISO 15552 adjustable-stroke cylinder featuring a built-in piston magnet. Its external stop screw allows you to trim the extend stroke by up to 40 mm on-site, providing a usable extend range of 60-100 mm from the 100 mm nominal maximum. As a direct, the SAIJ100X100-40S shares the exact interface, force, and mounting.
The SAIJ replacement retains the ISO 15552 mounting dimensions for seamless reuse of FA, LB, and TC brackets, and upgrades the piston seal to two Y-shaped one-way elements for lower start-up pressure and longer life. Choosing this adjustable stop often beats welding an external stop to a fixed SAI cylinder because it allows precise field tuning. Note the stop sets end position only; it is not a load lock.
Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-40S Technical Specifications
| Model | Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-40S |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAIJ100X100-40S |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAIJ100X100-40S carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
The SAIJ100X100-40S produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-40S
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-40S Is Used
Variable Press Stroke
Allows on-site extend stroke tuning up to 40 mm to accommodate material thickness variations without re-engineering the press fixture.
Adjustable Diverter Arm
Fine-tunes the extend reach of a sorting diverter on a conveyor line to handle varying package widths dynamically.
Calibrated Sealing Head
Provides precise end-position control for a packaging sealing head, allowing 60-100 mm stroke adjustments for different carton depths.
Replacing the Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-40S with the SAIJ100X100-40S
To replace the discontinued SIJ100X100-40S, order the SAIJ100X100-40S, ensuring you keep the -S suffix for the piston magnet required by legacy CS1-B/DS1-B switches. The 40 mm adjust window is ideal if your extend stroke needs on-site tuning between 60 and 100 mm. Mounting options include Basic, FA, LB, and TC using standard ISO 15552 interface dimensions. If your stroke exceeds 300 mm, carefully verify side-load limits to prevent rod binding. Remember, the stop screw sets end position but does not lock the load; for held loads use an external rod lock or SAIL/BSAI variant.
Replacement checklist
- ✓ Same ISO 15552 interface → SAIJ100X100-40S
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-40S FAQ
Yes, the SIJ100X100-40S is discontinued. The direct replacement is the SAIJ100X100-40S, which shares the same ISO 15552 interface, 100 mm bore, 40 mm adjust window, G1/2 port, and mounting options. The SAIJ family also upgrades the piston seal to two Y-shaped one-way elements for longer life.
The external stop screw allows you to trim the extend stroke by up to 40 mm on-site, yielding a usable extend range of 60-100 mm. The stop sets end position only and is not a load lock.
