Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-50S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X100-50S Dual-Rod Adjustable Cylinder Specifications
- Model: SIJ100X100-50S
- Type: Dual-rod double-acting cylinder with adjustable stroke
- Bore size: Ø100mm
- Stroke: 50mm (adjustable ±2mm via external stoppers)
- Operating pressure: 0.05–0.8 MPa
- Cushion type: Adjustable pneumatic cushion (both ends)
- Port size: G3/8 (NPT1/4 optional)
- Piston rod diameter: Ø25mm (chrome-plated steel)
- Max thrust: 628N @0.5MPa (extending)
- Operating temperature: -20℃ to 80℃
- Seal material: NBR with wear-resistant ring
- Body material: Aluminum alloy (anodized)
- Weight: 5.2kg (excluding accessories)
- Dimensions: 268mm(L) × 100mm(W) × 100mm(H)
- Rod center distance: 60mm (between dual rods)
- ISO standard: 15552
High-precision industrial cylinder featuring twin piston rods for enhanced moment resistance and positional accuracy. The through-rod design eliminates rotational movement during operation, while the external stroke adjustment mechanism allows fine-tuning without disassembly. Includes built-in magnetic sensor slots (M9 connector compatible) for position feedback.
- Precision clamping systems in CNC machining centers
- Vertical lifting mechanisms for assembly robots
- Position-locked fixtures for automotive welding lines
- Material handling systems requiring anti-rotation stability
- Packaging equipment with variable stroke requirements
Installation guidelines:
Mount using M8 fasteners (torque 22-25N·m) with parallelism tolerance ≤0.2mm/100mm.
Lubricate with ISO VG32 hydraulic oil before initial operation. For adjustable stroke setting:
1) Loosen lock nuts 2) Adjust stoppers 3) Secure with 1.5N·m torque.
Critical notes:
Avoid side-load exceeding 150N. Maximum allowable piston speed: 500mm/s.
Install rod-end supports when used in vertical orientation. Buffer adjustment
requires compressed air supply at ≥0.3MPa during calibration.
| Property | Property Value |
|---|---|
| sku | SIJ100X100-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
