This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAIJ100X100-75, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-75
The AirTAC SIJ100 Double Rod Adjustable Cylinder SIJ100X100-75 is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø100mm bore and 100mm stroke, G1/2 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAIJ100X100-75, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ100 mm
- Stroke100 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- StatusDiscontinued → SAIJ100X100-75
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-75
The AirTAC SIJ100X100-75 is a discontinued double-acting double-rod ISO 15552 adjustable-stroke cylinder. An external stop screw lets you trim the extend stroke by up to 75 mm on-site, yielding a usable 25-100 mm stroke from the 100 mm nominal maximum. The direct replacement is the SAIJ100X100-75, sharing the same interface, force, and mounting.
The SAIJ successor retains the adjustable cushion (36 mm) and adds an upgraded two Y-shaped one-way piston seal for lower start-up pressure and longer life. Note this SKU lacks a -S magnet and cannot take a switch; the stop screw sets end position but is not a load lock.
Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-75 Technical Specifications
| Model | Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-75 |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAIJ100X100-75 |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAIJ100X100-75 carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
The SAIJ100X100-75 produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-75
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-75 Is Used
Variable Depth Forming
Adjusting the extend stroke on-site by up to 75 mm allows operators to tune pressing depth for different material thicknesses without changing the entire cylinder.
Adjustable Transfer Stops
Trimming the extend stroke from 100 mm down to 25 mm accommodates varying package sizes on a conveyor line, providing flexible physical stopping points.
Replacing the Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-75 with the SAIJ100X100-75
To replace the discontinued SIJ100X100-75, order the direct replacement SAIJ100X100-75, keeping the identical 100 mm bore, 100 mm stroke, 75 mm adjust window, and G1/2 port. Choose the 75 mm adjust window if you need to trim the extend stroke down to 25 mm on-site. Mounting interchangeability via the ISO 15552 interface allows reusing FA, LB, or TC brackets. Because this SKU has no -S magnet, it cannot support legacy CS1-B/DS1-B sensors. For strokes of 300 mm or longer, verify side-load guidance to prevent rod binding.
Replacement checklist
- ✓ Same ISO 15552 interface → SAIJ100X100-75
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-75 FAQ
Yes, the SIJ100X100-75 is discontinued. The direct replacement is the SAIJ100X100-75, which shares the same ISO 15552 interface, 100 mm bore, 100 mm stroke, 75 mm adjust window, G1/2 port, and mounting options. The SAIJ family also features an upgraded piston seal.
This double-acting double-rod cylinder has a 75 mm adjust window, allowing the 100 mm nominal extend stroke to be shortened to 25 mm on-site. The external stop sets end position but does not hold the load on air loss.
