This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAIJ125X1000-10S, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-10S
The AirTAC SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-10S is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø125mm bore and 1000mm stroke, G1/2 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAIJ125X1000-10S, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ125 mm
- Stroke1000 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM27×2.0
- StatusDiscontinued → SAIJ125X1000-10S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-10S
The AirTAC SIJ125X1000-10S is a discontinued double-acting double-rod ISO 15552 adjustable-stroke cylinder. An external stop screw lets you trim the extend stroke by up to 10 mm on-site, giving a usable 990-1000 mm window. This stop sets the end position and is not a load lock.
The direct replacement is the SAIJ125X1000-10S, reusing the same interface and mounts. The SAIJ upgrade uses a two Y-shaped one-way piston seal for low start-up pressure.
Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-10S Technical Specifications
| Model | Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-10S |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAIJ125X1000-10S |
| Bore size | Ø125 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M27×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 40 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAIJ125X1000-10S carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø125mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 6136 N | 5734 N |
| 0.7 MPa | 8590 N | — |
| Max (@1.0 MPa) | 1251 kgf | |
The SAIJ125X1000-10S produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-10S
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 125 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-10S Is Used
Press Fit Tuning
Trimming the extend stroke by up to 10 mm on-site allows precise bottoming force for press fits without remachining hard stops.
Transfer Diverter
Adjusting the end position lets operators fine-tune a 990-1000 mm diverter gate reach to match varying pallet widths.
Stacker Alignment
Field stroke tuning accommodates minor height variations in stacking fixtures, ensuring accurate contact without repositioning sensors.
Replacing the Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-10S with the SAIJ125X1000-10S
Replace the discontinued SIJ125X1000-10S directly with the SAIJ125X1000-10S, retaining the ISO 15552 mounting interface and G1/2 port. Choose the 10 mm adjust window if you need minor end-position tuning rather than a fixed stop. Mounting options include FA, LB, and TC. The -S suffix provides a piston magnet for legacy CS1-B/DS1-B switches. Because stroke is 1000 mm, support the rod against bending and use external guides to manage side loads.
Replacement checklist
- ✓ Same ISO 15552 interface → SAIJ125X1000-10S
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-10S FAQ
Yes, the SIJ125X1000-10S is discontinued. The direct replacement is the SAIJ125X1000-10S, offering the same ISO 15552 interface, 125 mm bore, 1000 mm stroke, and G1/2 port. The SAIJ family also adds upgraded piston seals and lock variants like SAIL and BSAI.
The external stop screw window is 10 mm, allowing the extend stroke to be shortened from 1000 mm to 990 mm. The stop sets end position and is not a load lock.
