This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAIJ32X100-20TC, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-20TC
The AirTAC SIJ32 Double Rod Adjustable Cylinder SIJ32X100-20TC is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAIJ32X100-20TC, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → SAIJ32X100-20TC
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-20TC
The AirTAC SIJ32X100-20TC is a double-acting double-rod ISO 15552 adjustable-stroke cylinder, discontinued and replaced by the SAIJ32X100-20TC. The external stop screw lets you trim the extend stroke by up to 20mm on-site, giving a usable 80-100mm window from the 100mm nominal maximum.
The direct replacement SAIJ32X100-20TC shares the exact ISO 15552 interface, TC mount, and force, but upgrades to a two Y-shaped one-way piston seal for lower start-up pressure. The stop sets end position only; it is not a load lock, so use SAIL or an external rod lock to hold loads.
Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-20TC Technical Specifications
| Model | Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-20TC |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAIJ32X100-20TC |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAIJ32X100-20TC carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The SAIJ32X100-20TC produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-20TC
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-20TC Is Used
Diverter Gate Positioning
Trimming the extend stroke by up to 20mm on-site allows precise 80-100mm gate travel without machining spacers.
Variable Carton Sealing
The TC mount and adjustable stop let operators dial in exact flap contact pressure within the 100mm window.
Replacing the Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-20TC with the SAIJ32X100-20TC
Replace the discontinued SIJ32X100-20TC directly with the SAIJ32X100-20TC, retaining the TC mount and G1/8 port. The -20mm adjust window is ideal if your extend target sits between 80-100mm. This non-magnetic SKU lacks a -S sensor piston and cannot take a switch. For stroke lengths >=300mm, verify side-load guidance to prevent rod binding.
Replacement checklist
- ✓ Same ISO 15552 interface → SAIJ32X100-20TC
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-20TC FAQ
Yes, the SIJ32X100-20TC is discontinued. The direct replacement is the SAIJ32X100-20TC, sharing the same ISO 15552 interface, TC mount, 100mm stroke, 20mm adjust window, and G1/8 port.
The external stop screw trims the extend stroke by up to 20mm on-site, yielding an 80-100mm usable window. The stop sets end position and is not a load lock.
