Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-20
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-20 Dual Axis Adjustable Cylinder Specifications
- Full Model: SIJ50X100-20
- Bore Size: Ø50 mm
- Stroke: 100 mm (adjustable via external stoppers)
- Operating Pressure: 0.15–0.8 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Port Size: Rc1/4 (NPT1/4 optional)
- Mounting: Dual through-hole axis with 45mm center distance
- Body Material: Anodized aluminum alloy
- Rod Material: Stainless steel (SUS304)
- Piston Seal: NBR + PU hybrid seal ring
- Repeat Positioning Accuracy: ±0.5 mm
- Max Speed: 500 mm/s
- Lubrication: Pre-lubricated (Daphne Alpha No.1 compatible)
- Protection Rating: IP54 (standard), IP67 optional
- Weight: 3.2 kg ±5%
- Dimensions: 200mm(L) × 75mm(W) × 75mm(H)
High-precision dual-axis cylinder with mechanical position lock mechanism, featuring twin guide rods for enhanced moment resistance. The X-series variant includes chrome-plated secondary rods with 20mm adjustment range per side for fine positioning. Integrated shock absorbers reduce end-impact noise to <65 dB. Requires 5μm filtered air with dew point -25℃ or below.
- PCB board clamping & positioning in SMT machines
- Vertical lifting mechanisms in automotive welding jigs
- Precision glass panel handling robots
- Multi-station rotary index table systems
- Pharmaceutical blister packaging alignment
Installation guidelines:
Maintain parallel alignment within 0.2mm/m tolerance during mounting.
Apply thread locker (medium strength) on adjustment screws.
Perform initial 50-100 break-in cycles at 0.3 MPa before full load operation.
| Property | Property Value |
|---|---|
| sku | SIJ50X100-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
