Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-30
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-30 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ50X100-30
- Bore size: 50mm
- Stroke: 100mm (±5mm adjustable)
- Structure: Dual rod compact cylinder with guide rails
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting type: Standard MF1 (optional MF2/MF3 base mounts)
- Piston rod material: Hard chrome-plated steel (Cr-Mo)
- Cylinder tube: Aluminum alloy (anodized)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Port size: 1/4" NPT (G1/8 optional)
- Weight: 3.2kg (with rods and mounting brackets)
- Dimensions: 220mm(L) × 90mm(W) × 60mm(H)
- Rod diameter: 16mm (dual rods)
- Max lateral load: 180N (per rod)
- Repeat positioning accuracy: ±0.2mm
High-rigidity dual-axis cylinder featuring integrated linear guides and precision ground rods. The T-slot adjustment mechanism allows ±5mm stroke fine-tuning via hex key. Anti-rotation design ensures stable linear motion under heavy side loads. Includes magnetic piston for sensor mounting (SI-JM series sensors compatible).
- Precision clamping fixtures in CNC machining centers
- Vertical lifting mechanisms in packaging lines
- Positioning stages for optical component assembly
- Automated welding equipment guide systems
- Press-fit operations in electronic component manufacturing
Installation notes:
Lubricate guide rails with ISO VG32 hydraulic oil before initial use.
Avoid direct side impact on rods - use angular misalignment <0.5°.
For vertical mounting, install external guide supports when handling >5kg payloads.
| Property | Property Value |
|---|---|
| sku | SIJ50X100-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
