Airtac X-AHVSS Manual Valve X-AHVSS0303B
AirTAC X-AHVSS0303B Manual Valve Technical Details
- Model: X-AHVSS0303B
- Type: 3-position manual selector valve (lockable)
- Port configuration: 3 ports / 2 positions
- Port size: PT3/8 (G3/8 optional)
- Maximum pressure: 1.0 MPa
- Operating temperature: -5℃ to 60℃
- Flow capacity: 1200 NL/min (ANR)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR (hydrogenated nitrile)
- Handle type: Ergonomic T-bar with anti-slip grooves
- Actuation force: ≤2.5 N·m torque requirement
- Weight: 450g ±5%
- Dimensions: 82mm(L) × 62mm(W) × 38mm(H)
- Mounting: Panel mount with M5 fasteners
- Protection rating: IP54 (dust protected, water splashed)
Robust manual override valve featuring tactile position feedback and positive locking mechanism. The 90° rotation operation provides precise flow path selection, with chrome-plated brass internals ensuring corrosion resistance. Designed for systems requiring fail-safe manual intervention.
- Emergency shutdown systems in pneumatic circuits
- Production line mode selection (auto/manual)
- Hydraulic test bench pressure routing
- Mobile machinery manual override stations
- Process equipment maintenance bypass
Installation guidelines:
Apply thread sealant to port connections (PTFE tape not recommended).
Ensure handle rotation arc remains unobstructed. Perform monthly
lubrication of pivot points with silicone-based grease.
Do not exceed 120% of rated pressure.
Avoid rapid cycling (>1Hz). Compatible with ISO 8573-1:2010 Class 3 air quality.
| Property | Property Value |
|---|---|
| sku | X-AHVSS0303B |
