Airtac X-APGJ Reducer Straight Connector X-APGJ126
AirTAC X-APGJ126 Reducer Straight Connector Plug Technical Details
- Model: X-APGJ126
- Type: Metric thread reducer union plug (male to male)
- Material: Nickel-plated brass (CuZn39Pb3)
- Primary thread: M12×1.5 male
- Reducer thread: M10×1.0 male
- Pressure rating: 0.05-1.5 MPa
- Temperature range: -5℃ to 80℃ (non-condensing)
- Seal type: Metal-to-metal sealing with PTFE backup washer
- Torque limit: 30-35 N·m (lubricated)
- Surface hardness: HV0.3 ≥170 (nickel coating)
- Weight: 18.5±0.7g
- Dimensions: 28mm(Overall L) × 16mm(Hex W) × 16mm(Hex H)
- Compatibility: Works with ISO 1179-2 and DIN 3852-E standards
Precision-machined adapter for transitioning between metric pneumatic line sizes, featuring dual anti-vibration ridges and oxidation-resistant plating. The tapered thread design (74° seat angle) ensures leak-free connections in high-cycle applications. Includes integrated wrench flats for tool-assisted installation.
- Stepper motor pneumatic brake line reductions
- CNC machine tool sensor air line adapters
- Robotic end effector pressure port conversions
- Compressed air distribution manifolds
- Vacuum system component interfacing
Mounting protocol:
Apply 2-3 drops of pneumatic sealant (viscosity ≤1200 mPa·s) on threads before assembly.
Tighten 1.25 turns past finger-tight position. Avoid side-load forces exceeding 15N after installation.
| Property | Property Value |
|---|---|
| sku | X-APGJ126 |
