Airtac X-APMFT All Brass Female Thread Bulkhead Straight Fitting X-APMFT601
$5.49
Regular price
$12.99
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APMFT601
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APMFT601 Full Brass Bulkhead Male Thread Straight Fitting Specifications
- Model: X-APMFT601
- Type: Bulkhead male thread straight connector
- Material: C3604 free-cutting brass (lead-free compliant)
- Port size: PT1/8 (BSPP 1/8")
- Thread configuration: M5 internal thread × PT1/8 external thread
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Temperature range: -5℃ to 100℃ (with FKM seals)
- Surface treatment: Electrolytic nickel plating (3-5μm)
- Seal material: Standard NBR, optional FKM/Viton
- Weight: 28.5g ±0.5g
- Dimensions: 30mm(Total L) × 16mm(Hex) × 10mm(Through hole Ø)
- Torque specification: 2.0-2.5 N·m installation torque
- Certifications: RoHS 2.0, REACH SVHC
Heavy-duty bulkhead fitting with dual sealing structure (metal-to-metal seat + O-ring) for leak-free transitions through panels. Features 360° rotatable body post-installation for hose alignment. Anti-vibration knurling ensures tool-free hand tightening in confined spaces.
Typical Applications:
- Pneumatic cabinet pass-through connections
- Coolant line bulkhead installations in CNC machines
- Compressed air distribution manifolds
- Vacuum system interface ports
- Instrumentation panel mounting
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on external threads only.
Use backup wrench on hex flats during final tightening to prevent
rotation-induced hose torsion. Max panel thickness: 6mm.
