Airtac X-APVT Connector - Full Copper Elbow X-APVT12
AirTAC X-APVT12 Full Brass Elbow Fitting Specifications
- Model: X-APVT12
- Type: 90° Threaded Elbow Connector
- Material: Lead-free brass (RoHS compliant)
- Thread Standard: PT1/4 (BSPP) female threads both ends
- Alternative Threads: NPT1/4 or G1/4 available on request
- Max Working Pressure: 1.0 MPa (145 psi)
- Temperature Range: -20℃ to 120℃ (continuous use)
- Surface Treatment: Electroplated nickel finish (3-5μm)
- Seal Type: Integrated O-ring (NBR material)
- Torque Resistance: 15-20 N·m recommended installation torque
- Weight: 48g ±2g
- Dimensions: 32mm (L) × 28mm (W) × 24mm (H)
- Flow Coefficient: Cv ≈ 0.85
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
Precision-machined brass elbow for pneumatic systems, featuring dual anti-vibration grooves and self-aligning seat design. The electroless nickel plating provides enhanced corrosion resistance in humid environments. Internal flow path optimized for minimal pressure drop (ΔP < 0.02MPa @ 0.5MPa).
- Compact pneumatic cylinder port connections
- Vacuum system plumbing in semiconductor equipment
- Robotic arm tooling air supply lines
- Medical gas distribution panels
- Food-grade air line installations (certified NSF/ANSI 61)
Installation guidelines:
Apply PTFE tape clockwise on male threads (2.5 wraps recommended).
Avoid overtightening - stop rotation when 1-1.5 threads remain visible.
Pressure test at 1.5x operating pressure after installation.
