Airtac X-APZA Cross Four-Way Connector X-APZA6
AirTAC X-APZA6 Cross Fitting (Four-Way Connector) Technical Details
- Model: X-APZA6
- Type: Pneumatic cross fitting with 4-way equal division
- Thread Standard: PT1/8 (BSPP) / G1/8 (ISO 228)
- Material: Anodized aluminum alloy (AL6063-T5)
- Surface Treatment: Clear chromate coating
- Max Operating Pressure: 1.5 MPa (217 psi)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Seal Material: NBR (Nitrile) rubber
- Port Orientation: 90° orthogonal configuration
- Flow Coefficient (Cv): 0.65
- Weight: 48g ±2g
- Dimensions: 30mm (L) × 30mm (W) × 30mm (H)
- Torque Specification: 1.2-1.5 N·m during installation
Precision-machined cross connector designed for creating compact pneumatic distribution nodes. Features four M5x0.8 threaded ports with unified flow paths, optimized for minimal pressure drop (ΔP ≤0.02 MPa at 0.7 MPa input). The hexagonal body design allows tool-assisted tightening in confined spaces. Compatible with air, inert gases, and vacuum systems.
- Modular pneumatic control cabinets requiring multi-directional branching
- Vacuum pick-and-place system manifolds
- Medical device gas distribution units
- Robotic end-effector air circuit splitting
- Compressed air monitoring systems with multiple sensors
Installation Protocol:
Apply 1.5 wraps of PTFE tape on male threads (do not exceed 2 wraps).
Use counter-rotation technique during final tightening to maintain port alignment.
Pressure test at 1.8 MPa before system commissioning.
