Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1001B
AirTAC X-ASL1001B Limit-Entry L-Type Fitting Detailed Specifications
- Model: X-ASL1001B (L-Type Restricted Entry)
- Thread Standard: Metric (M5×0.8 internal thread)
- Material: Brass with nickel plating
- Seal Material: NBR (Nitrile Rubber)
- Applicable Tube OD: Ø4mm (for PU/Nylon tubing)
- Max Working Pressure: 1.0 MPa
- Temperature Range: -5℃ to 80℃
- Proof Pressure: 1.5 MPa
- Weight: 18.5g ±0.5g
- Dimensions: 18mm(L) × 18mm(W) × 15mm(H)
- Surface Roughness: Ra ≤1.6μm (sealing surfaces)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered L-shaped pneumatic connector featuring restricted-entry design to prevent overtightening damage. The 90° configuration optimizes space utilization in compact pneumatic systems while maintaining smooth airflow (CV value: 0.008). Anti-vibration teeth ensure secure tube retention under dynamic conditions.
- Robotic end-effector pneumatic circuits
- CNC machine tool clamp manifolds
- Semiconductor wafer handling equipment
- Packaging machine rotary joint interfaces
- Medical device pneumatic control panels
Installation Guide:
Insert tube until it bottoms out (audible click) before tightening.
Use 0.7-0.9N·m torque with compatible M5 adapters.
Apply silicone-free lubricant if used below -5℃.
Not recommended for hydraulic fluids or ester-based lubricants.
| Property | Property Value |
|---|---|
| sku | X-ASL1001B |
