Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1002
AirTAC X-ASL1002 Limit Insertion L-Type Fitting Technical Details
- Model: X-ASL1002 (L-Type Restricted Entry)
- Thread type: G1/8 (BSPP parallel thread)
- Material: Lead-free brass CW510L (RoHS compliant)
- Seal material: NBR (Nitrile) / Optional FKM (Fluorocarbon)
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Temperature range: -5℃ to 80℃ (NBR) / -20℃ to 120℃ (FKM)
- Installation torque: 1.2-1.5 N·m (recommended with thread sealant)
- Surface treatment: Electro-less nickel plating (8-12μm)
- Weight: 28g ±0.5g
- Dimensions: 25mm (L) × 16mm (W) × 28mm (H)
- Flow coefficient (Cv): 0.15
- Leakage rate: ≤3 bubbles/min (ISO 6952 test standard)
Precision-engineered L-shaped pneumatic connector featuring anti-disengagement safety design with dual-stage O-ring retention. The 45° angled port configuration enables space-saving plumbing in complex manifolds. Chrome-free surface treatment ensures environmental compliance while maintaining corrosion resistance in humid environments.
- Modular pneumatic circuit assembly in robotics
- Vacuum system interconnections
- Tool-changing mechanisms requiring vibration resistance
- Medical device pneumatic controls (FKM seal version)
- High-cycle automation equipment with frequent maintenance
Installation protocol:
Apply PTFE tape clockwise on male threads (2.5 wraps max).
Use torque wrench for final tightening - over-tightening may collapse
internal flow channels. Perform pressure test at 110% max working
pressure before initial operation.
| Property | Property Value |
|---|---|
| sku | X-ASL1002 |
