Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1002B
AirTAC X-ASL1002B Limit-Entry L-Type Fitting Specifications
- Model: X-ASL1002B
- Type: Limit-entry L-shaped push-to-connect fitting
- Thread Standard: Metric (M5×0.8 internal thread)
- Tube Compatibility: Ø4mm (1/8") OD pneumatic tubing
- Material: PA66 reinforced nylon (30% glass fiber)
- Pressure Rating: 0.05-1.0 MPa (7-145 PSI)
- Temperature Range: -20℃ to +80℃ (-4°F to +176°F)
- Seal Type: Integrated NBR O-ring (oil-resistant)
- IP Rating: IP40 (protected against 1mm solids)
- Weight: 8.5g ±0.3g
- Dimensions: 24mm(L) × 18mm(W) × 16mm(H)
- Certification: RoHS compliant, ISO 14001/9001
Engineered for secure pneumatic connections in confined spaces, this L-shaped fitting features a patented anti-disengagement design requiring 6.5N minimum pull-out force. The 85° angled flow path optimizes airflow dynamics while minimizing pressure drop. Color-coded blue collar indicates 4mm tube compatibility.
- Robotic end-effector pneumatic tooling
- CNC machine tool coolant control systems
- Semiconductor wafer handling equipment
- Compact medical ventilator assemblies
- High-cycle packaging machine actuators
Installation protocol:
Ensure tube end is cut square and deburred. Insert until audible click (2.5mm depth).
For maintenance, depress gray release collar fully before tube removal.
Do not use with silicone-based tubing materials.
| Property | Property Value |
|---|---|
| sku | X-ASL1002B |
