Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1004
AirTAC X-ASL1004 L-Type Restricted Entry Fitting Technical Details
- Model: X-ASL1004-(L)
- Type: L-shaped restricted entry (anti-pull-out) push-to-connect fitting
- Thread standard: ISO 228 G1/8 (BSPP parallel)
- Material: Brass body (nickel-plated) + PPS resin collar
- Seal material: HNBR rubber (FDA compliant option available)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃ (with silicone seals up to 120℃)
- Tube compatibility: Ø4mm polyurethane/nylon tubing (ID3mm)
- Insertion force: ≤30N (with safety lock engagement)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Weight: 18g ±0.5g
- Dimensions: 32mm(L) × 21mm(W) × 28mm(H)
- IP rating: IP54 (standard)/IP67 (with optional cap)
90° elbow pneumatic connector featuring patented dual-stage locking mechanism prevents accidental tube disconnection. The chrome-plated brass body ensures corrosion resistance in humid environments, while color-coded collars (standard blue) allow quick visual identification. Compatible with ISO 8573-1:2010 Class 3 compressed air quality.
- Robotic arm pneumatic circuits requiring tight-radius bends
- Food processing equipment needing frequent hose changes
- Semiconductor manufacturing cleanrooms
- Mobile hydraulic test bench connections
- Medical device pneumatic systems
Installation protocol:
Cut tube end square (max 0.5° angle), insert until audible click.
Verify lock by pulling with 50N force. Replace seal every 5,000
connections or 2 years (whichever comes first).
| Property | Property Value |
|---|---|
| sku | X-ASL1004 |
