Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL10M12
AirTAC X-ASL(L) Limit-Entry Push-in Fitting X-ASL10M12 Technical Details
- Model: X-ASL10M12 (L-Type Restricted Entry)
- Body material: Brass with nickel plating (corrosion resistant)
- Thread specification: M12×1.0 male thread (ISO 1179-2 standard)
- Tube compatibility: Ø10mm OD pneumatic tubing (PU/Nylon)
- Max operating pressure: 1.0 MPa (145 psi)
- Pressure range: 0.05-1.0 MPa
- Temperature range: -5℃ to +60℃ (fluid temperature)
- Seal material: HNBR (Hydrogenated Nitrile) for high oil resistance
- Insertion force: ≤50N (with lubricated tube)
- Extraction force: ≥20N (prevents accidental disconnection)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Weight: 28g ±1g
- Dimensions: 32mm(L) × 22mm(W) × 36mm(H) (excluding thread protrusion)
- Thread length: 12mm engagement length
- Color coding: Blue anodized collar (standard industrial identification)
90° angled pneumatic connector with positive-lock tube retention system, featuring dual-stage O-ring sealing and anti-rotation hex design. The L-shaped configuration optimizes space utilization in complex piping layouts while maintaining 0.5L/min airflow capacity at 0.5MPa. Zinc-nickel alloy coating provides 96hrs salt spray resistance per ASTM B117.
- Robotic arm end-effector pneumatic circuits
- CNC machine tool clamp actuators
- Packaging machine rotary joint interfaces
- Semiconductor wafer handling vacuum/pressure lines
- Food processing equipment (compatible with NSF-H1 lubricants)
Installation protocol:
Cut tubing square with dedicated cutter, deburr edges, and insert until audible click.
Always perform pull-out test (≥20N required). Not compatible with tapered threads.
