Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL10M16
AirTAC X-ASL10M16 L-Type Limit Insertion Fitting Specifications
- Model: X-ASL10M16-(L)
- Type: L-shaped restrictor fitting (push-in limit design)
- Material: Brass with nickel plating (RoHS compliant)
- Thread standard: M16×1.5 external thread (ISO 228-1)
- Seal type: Integrated O-ring with anti-extrusion ring
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (continuous use)
- Seal material: Oil-resistant NBR rubber (HNBR optional)
- Installation torque: 2.5-3.5 N·m (22-31 in-lb)
- Tube compatibility: Ø10mm polyurethane/nylon tubing
- Weight: 52g ±2g
- Dimensions: 38mm(L) × 20mm(W) × 20mm(H)
- Surface roughness: Ra ≤3.2μm (fluid contact surfaces)
- Pressure drop: ≤0.02 MPa @ 0.5 MPa supply
Precision-engineered L-shaped pneumatic connector featuring a patented anti-overinsertion design with dual-stage tube retention. The chamfered entry guide ensures smooth tube installation while preventing particulate ingress. Zinc-nickel composite coating provides enhanced corrosion resistance exceeding 96hrs in salt spray tests.
- Robotic arm pneumatic circuit junctions
- CNC machine tool air supply manifolds
- Food processing equipment (FDA-compliant variants)
- Semiconductor cleanroom pneumatic systems
- High-cycle automation tooling changers
Installation protocol:
Use open-end wrench on hex flats (22mm) during assembly.
Apply pneumatic sealant only on male threads, never on tube insertion area.
Maximum reconfiguration cycles: 15 times recommended.
Critical notes:
Requires filtered air (5μm absolute) with ISO 8573-1:2010 Class 3.4.2 quality.
Lubricate tubes with silicone grease (ISO VG 1 grade) before insertion.
| Property | Property Value |
|---|---|
| sku | X-ASL10M16 |
