Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL10M20
AirTAC X-ASL10M20 L-Type Restricted Entry Fitting Specifications
- Model: X-ASL10M20-(L)
- Type: L-shaped restricted entry push-to-connect fitting
- Thread standard: M20×1.5 (external thread)
- Material: Nickel-plated brass body + PPS resin collar
- Temperature range: -5℃ to 80℃
- Pressure range: 0-1.0 MPa
- Tube compatibility: Ø10mm polyurethane/nylon tubing
- Installation torque: 12-15 N·m
- Vibration resistance: ≤10 m/s² (ISO 10816-3)
- IP rating: IP54 (assembled state)
- Weight: 53g ±2g
- Dimensions: 30mm(L) × 20mm(W) × 25mm(H)
90° angled pneumatic connector with anti-accidental disengagement design, featuring dual-stage sealing (O-ring + metal-to-metal contact). The restricted entry mechanism prevents unintended tube insertion while maintaining single-hand operation capability. Chrome-plated internal flow path reduces air turbulence by 22% compared to standard fittings.
- Robotic arm pneumatic circuits requiring tight-space routing
- Food processing equipment needing frequent hose changes
- Mobile hydraulic test benches with vibration exposure
- Semiconductor cleanroom pneumatic systems
- Electric vehicle battery cooling line connections
Installation protocol:
Apply thread sealant (LOCTITE 577 recommended) on male threads before assembly.
Perform 5 full insertion-pullout cycles with empty tubing to seat seals properly.
Maximum reconnection cycles: 50 times.
| Property | Property Value |
|---|---|
| sku | X-ASL10M20 |
