Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1201
AirTAC X-ASL1201 L-Type Restricted Entry Fitting Specifications
- Model: X-ASL1201 (L-Type Restricted Entry)
- Body material: Brass with nickel plating
- Seal material: NBR (Nitrile) rubber
- Port thread: G1/8 (BSPP parallel thread)
- Applicable tubing OD: 6mm (1/4") to 8mm (5/16")
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Installation torque: 1.2~1.5 N·m (10.6~13.3 lb-in)
- Weight: 28g (0.06 lbs)
- Dimensions: 32mm(L) × 18mm(W) × 24mm(H)
- Anti-rotation design: Hexagonal base with 12mm wrench flat
- Flow characteristics: 150 NL/min (at 0.5 MPa)
- Compliance: RoHS compliant, REACH certified
L-shaped pneumatic connector featuring a restricted entry design to prevent accidental tube over-insertion. The 45° angled port configuration enables compact plumbing in tight spaces while maintaining smooth airflow. Chrome-plated brass construction ensures corrosion resistance in humid environments.
- Modular pneumatic manifold systems
- Robotic end-effector tooling connections
- CNC machine pneumatic circuit distribution
- Laboratory analytical instrument gas lines
- Packaging machine actuator networks
Installation note:
Apply 1.5-2 wraps of PTFE tape on male threads. Use tube insertion depth gauge (2.5mm from tube end to first barb) for leak-proof assembly. Avoid side-load stress during plumbing layout.
Critical:
Not compatible with polyurethane (PU) tubing exceeding 80℃. Always perform pressure decay test (0.8 MPa for 5min) after installation.
| Property | Property Value |
|---|---|
| sku | X-ASL1201 |
