Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1201B
AirTAC X-ASL1201B Limit-Entry L-Type Connector Specifications
- Model: X-ASL1201B
- Type: L-shaped limit-entry push-to-connect fitting
- Material: PBT+GF (30% glass fiber reinforced)
- Thread Standard: M5×0.8 external thread (ISO 6149 compliant)
- Seal Material: NBR rubber (replaceable O-ring)
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Tube Compatibility: Ø4mm (1/8") polyurethane/nylon tubing
- Installation Torque: 1.2-1.5 N·m (recommended)
- Vibration Resistance: ≤20 m/s² (MIL-STD-810G tested)
- Weight: 18g ±0.5g
- Dimensions: 30mm(L) × 18mm(W) × 16mm(H)
- Color Code: Light gray (RAL 7035 equivalent)
- Cycle Life: 50,000+ connections (with proper maintenance)
90° angled pneumatic connector featuring patented anti-disengagement design with triple-locking mechanism (thread lock, tube grip lock, and rotation prevention). The lead-free construction meets RoHS3 directives, while the internal flow path optimization ensures ≤0.15 MPa pressure drop at 5 L/min airflow. Includes integrated dust cap for unused ports.
- Robotic arm pneumatic tool changers
- CNC machine tool clamping systems
- Semiconductor wafer handling equipment
- Mobile hydraulic control panels
- Medical device pneumatic circuits
- EV battery cooling line connections
Installation protocol:
Engage tubing by pushing until audible click (3mm insertion depth).
Verify secure connection with 5N axial pull test. For maintenance,
depress stainless steel collet using dedicated removal tool (AT-3667).
