Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1202
AirTAC X-ASL1202-(L) Limit Insertion Type Elbow Fitting Specifications
- Model: X-ASL1202-(L)
- Type: Limit insertion L-shaped elbow (push-in fitting)
- Thread standard: BSPP (G1/8) / NPT1/8 optional
- Material: Nickel-plated brass body
- Seal material: HNBR rubber (high-temperature resistant variant)
- Operating temperature: -5℃ to 60℃
- Max working pressure: 1.0 MPa
- Tube compatibility: Φ4mm (5/32") OD pneumatic tubing
- Insertion force: ≤25N (with lock ring release mechanism)
- Vibration resistance: 5-2000Hz (anti-loosening design)
- Weight: 28g ±0.5g
- Dimensions: 31.5mm(L) × 16.2mm(W) × 15.8mm(H)
- Cycle life: >50,000 insertions (with original tube)
- Certification: RoHS compliant
Precision-engineered L-shaped pneumatic connector with patented anti-disengagement structure. Features triple sealing layers (thread seal, O-ring, and tube grip) for leak-free performance in dynamic applications. The 90° elbow design optimizes space utilization in compact pneumatic systems.
- Robotic arm end-effector pneumatic circuits
- CNC machine tool clamp actuators
- Lithium battery production line air blow systems
- Semiconductor wafer handling equipment
- High-cycle packaging machine valve manifolds
Installation protocol:
Cut tube ends square (max 0.5° bevel), insert fully until audible click.
For maintenance: Depress stainless steel lock ring using dedicated
disassembly tool (AT-7892 compatible). Avoid overtightening -
recommended torque 12-15N·m.
| Property | Property Value |
|---|---|
| sku | X-ASL1202 |
