Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1202B
AirTAC X-ASL1202B L-Type Restricted Entry Fitting Specifications
- Model: X-ASL1202B
- Type: L-shaped restricted entry (limit-in) pneumatic fitting
- Thread standard: Metric/PT hybrid design
- Port sizes: PT1/8 (G1/8 compatible)
- Material: Brass with nickel plating (surface hardness ≥HV200)
- Seal material: NBR (Nitrile) O-ring
- Operating pressure: 0.05-1.5 MPa
- Temperature range: -5℃ to 60℃
- Proof pressure: 2.25 MPa
- Flow coefficient (Cv): 0.55
- Weight: 28g ±1g
- Dimensions: 26mm(L) × 20mm(W) × 18mm(H) (body only)
- Installation torque: 1.0-1.5 N·m (recommended)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered L-shaped pneumatic connector featuring a patented anti-loosening groove design and 360° rotatable port alignment. The restricted entry design prevents accidental disconnection while maintaining 92% flow efficiency. Nickel-plated surface provides corrosion resistance (96hr salt spray test passed).
- High-vibration pneumatic tool connections
- Compact robotic arm end-effector piping
- Semiconductor manufacturing equipment
- Medical gas delivery systems
- Packaging machine rotary unions
Installation note:
Apply 1.5-2 wraps of PTFE tape on male threads at 45° angle.
Use backup wrench on hex base during tightening to prevent
tube deformation. Max re-use cycles: 5 times.
| Property | Property Value |
|---|---|
| sku | X-ASL1202B |
