Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1203
AirTAC X-ASL1203 L-Type Restricted Entry Fitting Specifications
- Model: X-ASL1203-(L)
- Type: L-shaped restricted entry (anti-disconnect) push-in fitting
- Port size: 1/8" (PT1/8/NPT1/8 compatible)
- Material: Brass with nickel plating (corrosion-resistant)
- Temperature range: -5℃ to 60℃
- Operating pressure: 0.05-1.0 MPa
- Tube compatibility: Ø4mm polyurethane/nylon tubing
- Thread standard: BSPP (G1/8)
- Insertion force: ≤50N
- Extraction force: ≥20N (with tube retention collar)
- Weight: 18g ±0.5g
- Dimensions: 28mm(L) × 16mm(W) × 24mm(H)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision L-shaped pneumatic connector featuring a patented dual-lock mechanism that prevents accidental tube disconnection. The 45° angled design enables compact plumbing in tight spaces while maintaining smooth airflow (CV value: 0.12). Includes built-in O-ring (NBR material) for positive sealing and stainless steel tube grip teeth for vibration resistance.
- Robotic arm pneumatic tooling connections
- CNC machine coolant line junctions
- Packaging equipment air distribution networks
- Laboratory instrument gas sampling systems
- Elevator brake pneumatic safety circuits
Installation protocol:
Cut tubing square (90°±2°) before insertion. Push until audible "click" confirms full engagement.
For maintenance: Press red release collar fully while pulling tubing. Max reusability: 50 cycles.
| Property | Property Value |
|---|---|
| sku | X-ASL1203 |
