Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1203B
AirTAC X-ASL1203B Restricted Entry Type L-Fitting Specifications
- Model: X-ASL1203B (L-Type Restricted Entry)
- Type: Male thread x Hose tail compression fitting
- Material: Nickel-plated brass body, NBR sealing
- Thread standard: Metric (M thread)
- Port sizes: M12×1.5 male thread x Ø12mm hose tail
- Max working pressure: 1.0 MPa (145 psi)
- Min burst pressure: 3.0 MPa (435 psi)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Weight: 38g ±2g
- Dimensions: 50mm(L) × 24mm(W) × 24mm(H)
- Surface treatment: Electroless nickel plating (5-8μm)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- IP rating: IP40 (dust protected)
Precision L-shaped pneumatic connector featuring a 90° flow path design with restricted entry thread to prevent overtightening. The dual-seal structure combines metal-to-metal sealing at the port interface and elastic sealing at the hose connection, ensuring zero leakage under dynamic pressure conditions. Includes anti-vibration grooves for secure hose retention.
- Compact pneumatic tool manifolds
- Robotic arm end-effector air supply lines
- CNC machine tool cooling systems
- Packaging machine rotary joint connections
- Semiconductor equipment gas distribution
Installation protocol:
Apply 2-3 drops of thread sealant (LOCTITE 577 recommended) on male threads before assembly.
Tighten to 12-15 N·m torque using crowfoot wrench. Maximum 1/2 rotation after contact with sealing surface.
| Property | Property Value |
|---|---|
| sku | X-ASL1203B |
