Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1204
AirTAC X-ASL1204 Limited Entry Type (L-Shape) Fitting Specifications
- Model: X-ASL1204-(L)
- Type: L-shaped restricted entry push-to-connect fitting
- Thread standard: BSPP (G thread)
- Port size: 1/4" (Rc1/4, G1/4, NPT1/4 compatible)
- Material: Brass body with nickel plating
- Seal material: NBR (Nitrile) O-ring
- Operating pressure: 0.05-1.5 MPa
- Temperature range: -5℃ to 60℃
- Flow coefficient (Cv): 0.85
- Weight: 82g ±2g
- Dimensions: 40mm(L) × 32mm(W) × 32mm(H)
- Tube compatibility: Φ4mm, Φ6mm, Φ8mm, Φ10mm, Φ12mm (selectable variants)
- Protection rating: IP40 (dust protected)
- Certification: RoHS compliant
L-shaped pneumatic connector with anti-contamination design featuring a built-in debris guard. The 360° rotatable collar enables tool-free tube installation while maintaining seal integrity. Nickel-plated surface resists corrosion in humid environments. Internal structure optimized for minimal pressure drop (ΔP ≤0.02MPa @1.0MPa).
- Pneumatic circuit branching in robotic end effectors
- Cleanroom-compatible machinery requiring particle control
- Medical device gas line connections
- Semiconductor manufacturing equipment
- Food processing pneumatic systems (NSF compliant variant available)
Installation protocol:
Insert tube until it bottoms out (audible click) and perform pull test.
For maintenance, depress the collet collar fully before tube removal.
Maximum recommended vibration: 4.9m/s². Not compatible with phosphate ester fluids.
| Property | Property Value |
|---|---|
| sku | X-ASL1204 |
