Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1204B
AirTAC X-ASL1204B Restricted Entry L-Type Fitting Specifications
- Model: X-ASL1204B
- Type: L-shaped restricted entry fitting (anti-intrusion design)
- Material: Brass with nickel plating
- Connection port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05-1.5 MPa
- Temperature range: -5℃ to 60℃
- Seal material: NBR rubber (FDA compliant option available)
- Surface hardness: HV0.3 ≥210
- Thread tolerance: ISO 1179-1 standard
- Protection rating: IP40 (dust protected)
- Installation method: Panel mount with O-ring seal
- Torque specification: 1.5-2.0 N·m (installation torque)
- Weight: 45g ±2g
- Dimensions: 30mm(L) × 24mm(W) × 24mm(H)
- Flow coefficient (Cv): 0.15
- Pressure drop: ≤0.02 MPa at 5 L/min flow
This corrosion-resistant L-shaped pneumatic fitting features a patented anti-rotation design with double O-ring sealing for leak-proof connections. The 90° angled configuration optimizes space utilization in complex piping layouts. Precision-machined threads ensure vibration resistance and compatibility with ISO-standard components. Includes built-in particle filtration ridges to prevent debris ingress during assembly.
- Compact pneumatic manifolds in robotics
- Modular assembly line equipment
- Medical device gas delivery systems
- Semiconductor manufacturing tools
- High-cycle automation stations
- Use torque wrench for precise tightening (1.8 N·m recommended)
- Align ports before final rotation (max 180° adjustment range)
- Apply thread sealant only on male threads (PT series)
- Perform pressure test at 1.75x working pressure after installation
Warning:
Do not use PTFE tape with NBR seals. Maximum angular misalignment tolerance: ±3°.
Replace O-rings every 50,000 cycles in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | X-ASL1204B |
