Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL12M16
AirTAC X-ASL(L) Series Limit Insertion Fitting X-ASL12M16 Technical Details
- Full model designation: X-ASL12M16-(L)
- Type: L-shaped restricted insertion push-in fitting
- Thread specification: M16×1.5 male thread
- Material: Lead-free brass (CuZn39Pb0.5) with nickel plating
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal material: NBR (Nitrile) O-ring
- Tube compatibility: Ø12mm OD pneumatic tubing
- Installation torque: 12-15 N·m recommended
- Weight: 78g ±2g
- Dimensions: 52mm (L) × 35mm (W) × 35mm (H)
- Surface hardness: ≥HV200
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Protection rating: IP40 (non-weatherproof)
Precision-engineered L-shaped pneumatic connector featuring anti-disengagement safety design with dual-lock mechanism (tube retention clip + thread locking). The chamfered entry guide enables single-handed tube insertion while preventing accidental release under pressure fluctuations. Nickel-plated surface provides corrosion resistance against hydraulic oils and mild chemicals.
- Pneumatic cylinder port connections in automated assembly lines
- Tool changer interfaces for CNC machining centers
- Modular pneumatic circuit junctions in packaging machinery
- Compressed air distribution in automotive brake test systems
- Vacuum line connections for semiconductor handling equipment
Installation protocol:
Apply 2-3 drops of pneumatic sealant (LOCTITE® 577 equivalent) on threads before final tightening.
Ensure tube end is cut square and deburred. Maximum angular deviation: ≤3° from fitting axis.
| Property | Property Value |
|---|---|
| sku | X-ASL12M16 |
