Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL401
AirTAC X-ASL401 Limit Entry Type (L-Type) Connector Specifications
- Model: X-ASL401
- Type: L-shaped restrictor fitting (limit entry design)
- Material: Brass with nickel plating
- Tube OD compatibility: Ø4mm (1/8") pneumatic tubing
- Thread specification: R1/8 (PT1/8)
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -5℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Proof pressure: 2.25 MPa
- Weight: 18g ±0.5g
- Dimensions: 28mm(L) × 16mm(W) × 16mm(H)
- Surface treatment: Electroless nickel plating (5-8μm)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Precision-engineered L-shaped pneumatic connector featuring anti-disengagement safety design with dual-stage tube retention. The 45° angled port configuration enables space-efficient plumbing in complex pneumatic circuits. Enhanced flow characteristics with internal radius optimization reduce turbulence by 22% compared to standard elbows.
- Robotic end-effector pneumatic networks
- CNC machine tool clamp circuits
- Packaging machine actuator clusters
- Laboratory automation gas distribution
- Semiconductor fab equipment
Installation protocol:
Insert tube until audible "click" engagement. Perform pull-out test with 5kgf force verification.
For maintenance: Depress stainless steel collet using dedicated release tool (X-TR401). Avoid overtightening -
recommended torque 1.2-1.5N·m.
| Property | Property Value |
|---|---|
| sku | X-ASL401 |
