Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL402
AirTAC X-ASL402-(L) Limit Entry Fitting Technical Details
- Model: X-ASL402-(L)
- Type: L-shaped restricted entry push-in fitting
- Port configuration: 2-way right angle (90° elbow)
- Thread standard: Metric (M5×0.8) & British (PT1/8) dual-standard compatible
- Material: Lead-free brass (CuZn39Pb3) with electroless nickel plating
- Operating pressure range: 0.05–1.5 MPa
- Burst pressure: ≥6.0 MPa
- Temperature range: -5℃ to 60℃
- Tube compatibility: Ø4mm polyurethane/nylon tubing
- Seal material: HNBR (Hydrogenated Nitrile) o-ring
- Vibration resistance: 1.5mm amplitude @ 10-60Hz
- Weight: 48g ±2g
- Dimensions: 30mm(L) × 25mm(W) × 35mm(H)
- Surface hardness: HV200-250
- Corrosion resistance: 96hrs neutral salt spray test passed
- IP rating: IP54 (standard installation)
High-density forged brass L-connector featuring anti-pullout collar design with 3-stage tube retention system. The precision-machined collet provides 360° uniform clamping force, maintaining leak-free performance under pressure fluctuations. Nickel plating enhances chemical resistance against hydraulic oils and mild acids.
- Compact pneumatic manifolds requiring space-saving 90° connections
- Vibration-intensive applications (robotic arms, CNC tool changers)
- Low-pressure hydraulic systems with HFD-R fluids
- Clean room equipment requiring metal-detectable components
- Modular pneumatic training systems with frequent tube reconfigurations
Installation protocol:
Insert tube until audible click (≥15mm insertion depth). Perform tug test with 50N force.
For high-cycle applications, inspect collet spring every 50,000 actuations.
Not recommended for axial load bearing - use support brackets if mechanical stress exceeds 2Nm.
| Property | Property Value |
|---|---|
| sku | X-ASL402 |
