Airtac X-EPGJ Connector - Reducer Straight Connector X-EPGJ1210
AirTAC X-EPGJ1210 Reducer Straight Connector Plug Technical Details
- Model: X-EPGJ1210
- Type: Male/Female reducer union (stepped through)
- Material: Brass (Nickel-plated surface)
- Thread Specifications:
- Large end: M12×1.0 male thread (external)
- Small end: M10×1.0 female thread (internal)
- Pressure rating: 0.05–1.5 MPa
- Temperature range: -5℃ to 80℃
- Seal type: NBR O-ring (replaceable)
- Surface hardness: HV0.3 ≥450
- Thread tolerance: 6g/6H per ISO 965-1
- Weight: 14.7±0.5g
- Dimensions: 30mm(Length) × 12mm(Major Ø) × 10mm(Minor Ø)
- Vibration resistance: ≤5Hz @ 1.5mm amplitude
- Corrosion resistance: 96hrs neutral salt spray test passed
Precision-machined transition fitting for pneumatic line downsizing, featuring dual-thread configuration with leak-proof stepped design. The chrome-plated brass construction ensures durability in high-cycle applications. Compatible with ISO 8434-1/DIN 2353 standards for metric tube connections.
- Pressure regulator outlet reduction in compressed air systems
- Sensor mounting port adaptation in automation machinery
- Branch line creation with flow restriction in pneumatic circuits
- Tool changer interface conversion for robotic arms
- Medical device gas line interconnection
Mounting guidance:
Apply 2-3 drops of pneumatic sealant (viscosity ≤35 mPa·s) on threads before assembly.
Tighten with 8-10 N·m torque using crowfoot wrench. Avoid cross-threading - align axis
within ±0.5° during connection. Perform pressure test at 1.75× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-EPGJ1210 |
