Airtac X-EPZA Cross Four-way Connector X-EPZA10
$3.84
Regular price
$11.34
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPZA10
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPZA10 Cross Fitting (4-Way Cross Connector) Specifications
- Model: X-EPZA10
- Type: Pneumatic cross connector with 4 ports
- Thread standard: Metric (M5x0.8)
- Material: Nickel-plated brass (body), NBR seals
- Max working pressure: 1.0 MPa
- Proof pressure: 1.5 MPa
- Burst pressure: ≥3.0 MPa
- Operating temperature: -5℃ to 80℃ (with NBR seals)
- Weight: 50g ±2g
- Dimensions: 25mm(L) × 25mm(W) × 25mm(H)
- Port configuration: 4 × M5 female threads (orthogonal)
- Surface treatment: Electroless nickel plating (8-12μm)
- Flow coefficient (Cv): 0.15
Precision-engineered cross connector featuring zero-leak design with double O-ring seals at each port. The compact cubic shape enables space-efficient plumbing in multi-directional pneumatic circuits. Nickel plating provides corrosion resistance for humid environments.
Typical Applications:
- Pneumatic manifold distribution blocks
- Multi-axis robotic tool changers
- Air pressure balancing systems
- Modular assembly fixtures
- Medical gas line distribution
- Automated packaging machine air networks
Installation guidelines:
Apply 360° thread sealant (LOCTITE 545 or equivalent) on male threads.
Tighten to 1.2-1.5 N·m torque using crowfoot wrench. Avoid overtightening
which may distort sealing surfaces. Test at 0.8 MPa for 5 mins post-installation.
| Property | Property Value |
|---|---|
| sku | X-EPZA10 |
