Airtac X-EPZA Cross Four-way Connector X-EPZA12
AirTAC X-EPZA12 Cross Tee Fitting Technical Details
- Model: X-EPZA12
- Type: Pneumatic cross tee union (4-way connector)
- Body material: Nickel-plated brass (stainless steel optional)
- Thread standard: PT1/8 (BSPP) / NPT1/8 available
- Port configuration: 4 female threaded ports (90° cross)
- Pressure rating: 0.5-1.6 MPa (72-232 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) O-rings
- Surface treatment: Electrolytic polishing (Ra ≤0.8μm)
- Weight: 118g ±2g
- Dimensions: 40mm(L) × 40mm(W) × 40mm(H) (cube body)
- Port depth: 10mm engagement length
- Certification: ISO 8434-1 / DIN 2353 standards
High-flow cross connector featuring precision-machined internal channels (2.8mm flow diameter) with turbulence-reducing design. The nickel-plated body resists corrosion in humid environments (salt spray tested 96hrs). Compatible with air, inert gases, and vacuum systems. Includes built-in O-ring grooves for positive sealing without additional washers.
- Central distribution node in pneumatic control panels
- Multi-axis actuator synchronization systems
- Vacuum circuit branching for pick-and-place robots
- Compressed air manifolds in automotive assembly lines
- Medical gas line distribution (oxygen/nitrogen systems)
Mounting guidance:
Apply 3-5Nm torque during installation. Use thread sealant only on male ports -
avoid contaminating O-ring surfaces. For vertical installations, orient identification
markings upward for service accessibility.
