Airtac 2KWX Fluid Solenoid Valve 2KWX05010EI
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX05010EI Fluid Solenoid Valve Specifications
- Model: 2KWX05010EI
- Type: 5/2-way monostable (solenoid pilot operated)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.82 kg (1.81 lbs)
- Dimensions: 98mm(L) × 45mm(W) × 57mm(H)
- Seal material: NBR (Nitrile) standard, optional FKM/Viton for high temp
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Power consumption: DC24V: 3.5W | AC110V: 4.2VA | AC220V: 4.5VA
- Protection rating: IP67 (dustproof & temporary immersion)
- Fluid compatibility: Compressed air (lubricated/non-lubricated), inert gases
- Response time: ≤15ms (at 0.5MPa)
High-flow directional control valve with aluminum alloy body and manual override. Features low-hysteresis electromagnetic design for precise cylinder control in heavy-duty applications. Integrated LED indicator shows operational status. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.3 purity standards.
- Industrial pressurization systems
- Automated assembly line actuators
- Plastic injection molding machines
- Semiconductor vacuum handling
- Food-grade pneumatic systems (with FKM seals)
- Test bench pressure regulation
Installation note:
Install with vibration-damping mounts in high-cycle applications (>5Hz).
Maintain 15mm clearance on pilot exhaust ports. Use ISO 15407-1 compliant
lubricant if manual override requires smoothing.
| Property | Property Value |
|---|---|
| sku | 2KWX05010EI |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
