AirTAC 4V Series · 5/3-way Solenoid Valve

Airtac 4V100 Solenoid Valve 4V130C-M5-A

The AirTAC 4V100 Solenoid Valve 4V130C-M5-A is a genuine 5/3-way 5/3 double solenoid — closed center solenoid valve with M5 ports and an effective area of 8.6 mm² (Cv 0.51). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.

  • Valve type5/3-way
  • Function5/3 double solenoid — Closed center
  • Port sizeM5
  • Effective area8.6 mm²
  • Flow (Cv)0.51
  • Series4V100
$51.40 $58.90Save 12% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every 4V130C-M5 stroke, mounting and version on one page All 4V130C-M5 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac 4V100 Solenoid Valve 4V130C-M5-A

The AirTAC 4V130C-M5A is a 5/3-way double-solenoid pneumatic valve built on the compact 4V100 body, directing compressed air to small double-acting actuators. In its closed-center configuration, both cylinder ports are blocked when the valve is de-energized, holding the actuator in position mid-stroke—ideal for short stops or pause points in a sequence. With an M5 threaded port and AC220V coil drawing 3.5 VA, this terminal-box model integrates easily into benchtop automation running on mains power.

This 5/3 spool valve provides an effective area of 8.6 mm² (Cv 0.51, catalog figure for the 4V130C-06) and a maximum cycling rate of 3 cycles per second. The aluminum-alloy body weighs 200 g, and the sliding-column design delivers a fast response of 0.05 seconds or less. Operating pressure spans 0.15–0.8 MPa, and the IP65-rated enclosure with class-B insulation ensures reliable switching in light industrial environments.

Closed-center stopping is not a load-holding or safety function: air leakage can let the cylinder creep, so add a pilot check valve or a mechanical brake where a load must be held.

Airtac 4V100 Solenoid Valve 4V130C-M5-A Technical Specifications

ModelAirtac 4V100 Solenoid Valve 4V130C-M5-A
Series4V100 solenoid valve (spool type)
Valve type5/3-way
Function5/3 double solenoid — Closed center
Port sizeM5
Exhaust portM5
Effective area (Cv)8.6 mm² (Cv 0.51)
FluidAir (filtered by 40µm element)
Pilot typeInternal / external pilot
Operating pressure0.15 – 0.8 MPa
Proof pressure1.2 MPa
Max frequency3 cycle/sec
Response time≤ 0.05 s (activating)
Temperature-20 to +70 °C
Body materialAluminum alloy
Weight200 g

Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.

Flow & Coil Options

Effective area8.6 mm²
Flow coefficientCv 0.51
Response time≤ 0.05 s
Coil powerAC 3.5 VA · DC24V 2.8 W · DC12V 2.5 W
Protection / insulationIP65 (DIN40050), B-class
Voltage optionsDC24V, DC12V, AC110V, AC220V
Manual overrideYes (locking / non-locking)

Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.

Model Code: Airtac 4V100 Solenoid Valve 4V130C-M5-A

4VSolenoid valve, spool type, 4-series.
1Body size (4V100) — sets port & flow.
3Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3.
-M5Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2".

Related: 4V110 (single), 4V120 (double), 4V130C/E/P (5/3 center). Add the voltage suffix when ordering.

Where the Airtac 4V100 Solenoid Valve 4V130C-M5-A Is Used

precision_manufacturing

Small Part Clamping

The closed-center function holds a miniature clamp in place mid-cycle.

science

Benchtop Fluid Handling

Pauses a syringe pump or dispenser actuator at a precise point. The M5 port and AC220V power suit laboratory automation setups with mains voltage available.

settings_input_component

Pick-and-Place Z-Stop

Stops a small pick-and-place arm mid-stroke for inspection or orientation change. The 3 c/s max frequency matches intermittent indexing moves on a desktop cell.

Is the Airtac 4V100 Solenoid Valve 4V130C-M5-A the Right Valve?

Choose the 4V130C-M5A when you need a small-body 5/3 valve to pause a double-acting cylinder. The closed center blocks ports A and B, making it suitable for short holding operations on small clamps or grippers where a brief stop is required. If your cylinder is larger than about 32 mm bore or you need a faster cycle rate, step up to the 4V200 series (Cv 1.0) for higher flow capacity.

For replacement, match five points precisely: confirm the 4V100 body size, 5/3 closed-center function, M5 port thread, AC220V coil voltage, and terminal-box electrical entry. A single valve can be mounted individually, or you can build a manifold group on a common base for multi-cylinder circuits. Always verify that your application does not require a dedicated mechanical brake for safety-critical load holding.

Quick checklist

  • ✓ Required flow (Cv) for cylinder & speed
  • ✓ Function: single / double / 5-3 center
  • ✓ Coil voltage (DC24 / AC220 …)
  • ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
  • ✓ Single valve or manifold base?
Ask an Engineer

Installation & Wiring Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 0.8 MPa operating pressure.
  • check Match coil voltage to your controller output.
  • check Use the manual override to test before powering.
  • check Fit silencers or fittings to the exhaust ports.
  • check Wiring by qualified personnel per AirTAC docs.

Airtac 4V100 Solenoid Valve 4V130C-M5-A FAQ

With an effective area of 8.6 mm² (Cv 0.51, catalog figure for the 4V130C-06), this valve suits double-acting cylinders roughly in the Ø16–32 mm range for typical cycling. The closed-center design is meant for applications that need a mid-stroke pause, not continuous high-speed reciprocation. For larger bores or faster actuation, consider moving to the 4V200 series with a higher Cv.

When both solenoids are de-energized, the spool blocks all ports, which can hold a cylinder in position temporarily against balanced forces. However, this is not a safety-rated holding brake. Any vertical or suspended load requires a separate mechanical brake or pilot-operated check valve at the cylinder ports to prevent unintended movement.
