The AirTAC 4V100 Solenoid Valve 4V130E-M5-A is a genuine 5/3-way 5/3 double solenoid — exhaust center solenoid valve with M5 ports and an effective area of 8.6 mm² (Cv 0.51). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
The AirTAC 4V130E-M5A is a 5/3-way double solenoid valve from the compact 4V100 series, configured with an exhaust center function and M5 threaded ports. When both solenoids are de-energized, the spool moves to the center position, connecting both cylinder ports (A and B) to exhaust. This allows a double-acting cylinder to float freely, making it ideal for applications where the load must be manually positioned or moved without air resistance when the valve is at rest.
Operating on an AC220V coil drawing 3.5 VA, this valve directs air to small actuators with an effective area of 8.6 mm² (Cv 0.51, catalog figure for the 4V130C-06). The aluminum-alloy body weighs 200 g and features a sliding-column spool design with a response time of 0.05 seconds or less. With IP65 protection and a maximum cycling frequency of 3 cycles per second, it suits benchtop automation tasks where a floating center position is a functional requirement.
| Model | Airtac 4V100 Solenoid Valve 4V130E-M5-A |
|---|---|
| Series | 4V100 solenoid valve (spool type) |
| Valve type | 5/3-way |
| Function | 5/3 double solenoid — Exhaust center |
| Port size | M5 |
| Exhaust port | M5 |
| Effective area (Cv) | 8.6 mm² (Cv 0.51) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 200 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
| Effective area | 8.6 mm² |
|---|---|
| Flow coefficient | Cv 0.51 |
| Response time | ≤ 0.05 s |
| Coil power | AC 3.5 VA · DC24V 2.8 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 1 | Body size (4V100) — sets port & flow. |
| 3 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -M5 | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V110 (single), 4V120 (double), 4V130C/E/P (5/3 center). Add the voltage suffix when ordering.
In a small assembly station, the 4V130E-M5A allows a worker to manually slide a pneumatic gripper into position when the valve is de-energized, as the exhaust center lets air escape from both sides of the cylinder.
For a benchtop test fixture, this valve controls a small clamp. The exhaust center ensures the clamp releases completely and floats free when power is removed, preventing any residual pressure from holding the part.
In a lab automation device, the 4V130E-M5A cycles a small double-acting actuator. The AC220V coil integrates easily with mains-powered control panels, and the floating center position allows for safe, pressure-free sample loading.
Select the 4V130E-M5A when your pneumatic circuit needs a 5/3 exhaust center valve on an M5 port base. The exhaust center is specifically for applications where the cylinder must be de-pressurized at rest, allowing the rod to be moved freely—common in manual load-assist or clamping setups where the operator needs to reposition the tooling by hand. If your cylinder is larger than a 32 mm bore or you need faster cycle times, evaluate stepping up to the 4V200 series, which provides a higher Cv of 1.0.
For a direct replacement, match five points: the 4V100 body size, the 5/3 exhaust center function, the M5 port size, the AC220V coil voltage, and the standard terminal box electrical entry. This valve can be mounted individually or on a manifold base, and the manual override allows for circuit testing without energizing the coil.
AirtacDistr lists every 4V130E-M5 order code with its price on one page at https://airtacdistr.com/products/airtac-4v130e-m5-solenoid-valve
Quick checklist
In the center position (both solenoids off), the valve connects both cylinder ports (A and B) to the exhaust ports (R and S). This depressurizes the cylinder, allowing the piston rod to be moved freely by an external force. It is the correct choice when you need the actuator to 'float' at rest, rather than holding a position or being blocked.
With an effective area of 8.6 mm² (Cv 0.51, catalog figure for the 4V130C-06), this 4V100 series valve is well-suited for driving small bore double-acting cylinders, typically in the Ø16 to Ø32 mm range. For larger cylinders or applications requiring a faster cycle rate, a valve from the 4V200 series with a higher Cv would be a more appropriate choice.
