AirTAC 4V Series · 5/2-way Solenoid Valve

AirTAC 4V420-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V42015AI)

The AirTAC 4V420-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V42015AI) is a genuine 5/2-way double solenoid (memory) solenoid valve with PT1/2 ports and an effective area of 48.0 mm² (Cv 2.82). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.

  • Valve type5/2-way
  • FunctionDouble solenoid (memory)
  • Port sizePT1/2
  • Effective area48.0 mm²
  • Flow (Cv)2.82
  • Series4V400
$70.94 $78.44Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every 4V420-15 stroke, mounting and version on one page All 4V420-15 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the AirTAC 4V420-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V42015AI)

The AirTAC 4V420-15AI is a 5/2-way double-solenoid directional control valve built on the largest 4V body size, directing compressed air to double-acting cylinders and actuators with a substantial Cv of 2.82 (48.0 mm² effective area). Its defining characteristic is a two-coil memory spool: a momentary pulse to coil A shifts the valve and it mechanically stays there—even through a complete power loss—until a pulse to coil B resets it. This model arrives pre-wired for AC220V via a grommet-style 0.5 m flying lead, making installation in DIN-rail panels straightforward.

With a response time of 0.05 seconds or less and a maximum cycling rate of 3 cycles per second, the 4V420-15AI suits the actuation demands of bore sizes roughly Ø80–125 mm. The aluminum-alloy body weighs 720 g, operates on filtered, non-lubricated air from 0.15–0.8 MPa, and carries an IP65 protection rating. Its memory function eliminates the heat and energy consumption of a continuously energized coil, a practical advantage in long-dwell clamping or holding stations.

AirTAC 4V420-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V42015AI) Technical Specifications

ModelAirTAC 4V420-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V42015AI)
Series4V400 solenoid valve (spool type)
Valve type5/2-way
FunctionDouble solenoid (memory)
Port sizePT1/2
Exhaust portPT1/2
Effective area (Cv)48.0 mm² (Cv 2.82)
FluidAir (filtered by 40µm element)
Pilot typeInternal / external pilot
Operating pressure0.15 – 0.8 MPa
Proof pressure1.2 MPa
Max frequency3 cycle/sec
Response time≤ 0.05 s (activating)
Temperature-20 to +70 °C
Body materialAluminum alloy
Weight720 g

Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.

Flow & Coil Options

Effective area48.0 mm²
Flow coefficientCv 2.82
Response time≤ 0.05 s
Coil powerAC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W
Protection / insulationIP65 (DIN40050), B-class
Voltage optionsDC24V, DC12V, AC110V, AC220V
Manual overrideYes (locking / non-locking)

Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.

Model Code: AirTAC 4V420-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V42015AI)

4VSolenoid valve, spool type, 4-series.
4Body size (4V400) — sets port & flow.
2Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3.
-15Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2".

Related: 4V410 (single), 4V420 (double), 4V430C/E/P (5/3 center). Add the voltage suffix when ordering.

Where the AirTAC 4V420-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V42015AI) Is Used

handyman

Heavy-Duty Clamping Fixtures

Pulse the 4V420-15AI to clamp a large workpiece, then cut coil power entirely. The memory spool keeps full clamping force on a double-acting cylinder indefinitely, saving energy and preventing heat build-up in the AC220V coil during long production runs.

conveyor_belt

Large-Bore Diverter Gates

Control a pneumatic gate on a conveyor handling pallets or bulky packages. A momentary signal opens the gate; it stays open without holding current. A second pulse closes it, providing a simple two-wire control scheme that survives power cycling.

precision_manufacturing

Vacuum Pick-and-Place Heads

In a pick-and-place end-effector with a Ø100 mm vacuum cylinder, the 4V420-15AI’s memory function holds the part securely even if the robot controller enters a paused state. The 0.05 s response ensures crisp part release when the reset coil fires.

Is the AirTAC 4V420-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V42015AI) the Right Valve?

Choose the 4V420-15AI when your application needs a 5/2 valve that must hold its last position without consuming power—ideal for vacuum cups, clamps, or gates where a spring-return would be unsafe during an E-stop. Because this is a double-solenoid memory valve, you wire two momentary signals instead of one constant signal. If your cylinder is closer to Ø63 mm or smaller, the 4V300 body (Cv ~1.65) is a better match and avoids oversizing. For flow rates beyond what the 4V400’s 1/2-inch ports can deliver, consider moving to a larger series or ganging multiple 4V400 valves on a manifold.

For a direct replacement, match five points exactly: the 4V400 body size, the 20 (double-solenoid) function, 1/2-inch PT-threaded ports, an AC220V coil, and the grommet (I) electrical entry. This specific AC220V grommet configuration is popular in European-style control cabinets where a flying lead connects directly to a terminal strip without a bulky junction box.

AirtacDistr lists every 4V420-15 order code with its price on one page at https://airtacdistr.com/products/airtac-4v420-15-solenoid-valve

Quick checklist

  • ✓ Required flow (Cv) for cylinder & speed
  • ✓ Function: single / double / 5-3 center
  • ✓ Coil voltage (DC24 / AC220 …)
  • ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
  • ✓ Single valve or manifold base?
Ask an Engineer

Installation & Wiring Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 0.8 MPa operating pressure.
  • check Match coil voltage to your controller output.
  • check Use the manual override to test before powering.
  • check Fit silencers or fittings to the exhaust ports.
  • check Wiring by qualified personnel per AirTAC docs.

AirTAC 4V420-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V42015AI) FAQ

The double-solenoid design is a mechanically held memory valve. The spool stays in whichever position it was last pulsed to, kept in place by land friction and balanced pressure—there are no springs and no holding current. It will not shift until the opposing coil receives a deliberate electrical signal.

With a Cv of 2.82 and a 48.0 mm² effective area, the 4V420-15AI is typically paired with double-acting cylinders in the Ø80–125 mm range. The AC220V coil draws 4.5 VA inrush, and the grommet entry provides a 0.5 m flying lead for direct connection inside a control cabinet.
