This model is discontinued

AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACE100X15, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.

AirTAC ACP Series · Discontinued Compact Cylinder

Airtac ACP Compact Cylinder ACP100X15

The AirTAC ACP Compact Cylinder ACP100X15 is a double acting DIN-standard tight/compact air cylinder with a Ø100mm bore and 15mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACE100X15 (ISO 21287 ACE), in the same bore, stroke and force class.

  • BoreØ100 mm
  • Stroke15 mm
  • Port size1/4"
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • StatusDiscontinued → ACE100X15
$149.55 $163.33Save 8% Ships as ACE100X15 (current AirTAC replacement)
Ships as ACE100X15, the current AirTAC replacement (the same code under the new prefix). Order this code as usual. Your cart, checkout and order confirmation will show the ACE100X15 we ship. View ACE100X15
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every ACP100 stroke, mounting and version on one page All ACP100 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac ACP Compact Cylinder ACP100X15

A double acting compact cylinder in the DIN-standard ACP series, the ACP100X15 pairs a 100 mm bore with a very short 15 mm stroke and a 25 mm hard-chrome S45C rod on a hard-anodized aluminium body. At 0.5 MPa it pushes 3927 N and pulls 3681.6 N; at 0.7 MPa that rises to 5497.8 N push, with a theoretical peak of 800.9 kgf at 1.0 MPa. The short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into dense press fixtures and guarding where a full-length bore-100 body will not fit.

A fixed TPU bumper sits at both ends. This model is discontinued: the current-production successor is the ACE100X15 in the same bore, stroke and force class, so confirm the ISO 21287 mounting dimensions before swapping.

Airtac ACP Compact Cylinder ACP100X15 Technical Specifications

ModelAirtac ACP Compact Cylinder ACP100X15
SeriesACP DIN compact cylinder (discontinued)
ReplacementACE100X15
Bore sizeØ100 mm
Stroke15 mm
Acting typeDouble acting
Port size1/4"
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed bumper (both ends)
Max standard strokeUp to 300 mm

Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACE100X15 (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.

Theoretical Output Force (Ø100mm)

PressurePush forcePull force
0.5 MPa3927 N3682 N
0.7 MPa5498 N5154 N
Max (@1.0 MPa)801 kgf

The ACE100X15 produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.

Model Code: Airtac ACP Compact Cylinder ACP100X15

ACPDIN compact cylinder (double-acting, discontinued).
100Bore size in mm.
×15Stroke length in mm.
SOptional built-in magnet for sensor position sensing (omit for no magnet).
BRod type: B = male thread; blank = female thread.

Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).

Where the Airtac ACP Compact Cylinder ACP100X15 Is Used

compress

Short-stroke die clamping

The 15 mm stroke and 3927 N push at 0.5 MPa suit punch-press die clamps on stamping lines, where the compact body fits between bolster plates that exclude a full-length cylinder.

factory

Press-fit riveting heads

With about 2356 N of practical working force at 0.5 MPa, this bore drives light riveting and press-fit heads on appliance and automotive sub-assembly stations.

Replacing the Airtac ACP Compact Cylinder ACP100X15 with the ACE100X15

At bore 100 you are at the top of the range - the next size down, bore 80, delivers 2513 N push at 0.5 MPa, so choose ACP100X15 only when your load genuinely needs the 3927 N class. Stroke 15 mm is well inside the 300 mm maximum standard stroke for this bore. The female M16x1.5 rod thread and 1/4" PT ports suit large-bore plumbing; FA/FB flange, LB foot, CA/CB clevis and related brackets bolt to the mounting face. If you need position feedback, order the -S variant, since the magnet is optional and CMSE / DMSE switches only work with it. Remember the piston drifts when air is lost, so add a rod lock or pilot check valve for held loads. For new projects, specify the ACE100X15 instead.

Replacement checklist

  • ✓ Current-production ACE → ACE100X15
  • ✓ Same bore / stroke / force class
  • ✓ Confirm ISO 21287 mounting dimensions
  • ✓ Port/thread type (PT / G)
  • ✓ Add -S for magnet if you need sensors
View ACE100X15

Airtac ACP Compact Cylinder ACP100X15 FAQ

Push is 3927 N and pull 3681.6 N at 0.5 MPa; at 0.7 MPa push reaches 5497.8 N, with a theoretical maximum of 800.9 kgf at 1.0 MPa. It is a double acting compact cylinder, 100 mm bore, 15 mm stroke, 25 mm rod, 1/4" PT ports, female M16x1.5 rod thread, operating on 0.15-1.0 MPa (22-145 psi) air filtered to 40 um, at 30-500 mm/s and -20 to +70 C. The model is discontinued; the ACE100X15 is the current replacement.

It has a hard-anodized aluminium body with threaded aluminium covers, an S45C hard-chrome piston rod and a fixed TPU bumper at each end; the short body saves about 50% of the mounting length of an ISO 15552 profile cylinder. Sensors are possible only on the -S variant, which carries the optional magnet for CMSE / DMSE switches - this standard code has no magnet. Mounting brackets such as FA/FB flange, LB foot and CA/CB clevis attach to the same face; confirm ISO 21287 dimensions when moving to the ACE100X15.
