This model is discontinued
AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACE100X150B, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACP Compact Cylinder ACP100X150B
The AirTAC ACP Compact Cylinder ACP100X150B is a double acting DIN-standard tight/compact air cylinder with a Ø100mm bore and 150mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACE100X150B (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke150 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM16×1.5
- StatusDiscontinued → ACE100X150B
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACP Compact Cylinder ACP100X150B
The ACP100X150B is a double acting compact cylinder in the discontinued AirTAC ACP DIN-standard series, with a 100 mm bore, 150 mm stroke and a male rod thread (B code). At 0.5 MPa it pushes 3927 N and pulls 3681.6 N; at 0.7 MPa that rises to 5497.8 N push and 5154.2 N pull, with a theoretical maximum of 800.9 kgf at 1.0 MPa. Air is the only fluid, filtered to 40 um, at 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), running 30-500 mm/s between -20 and +70 C.
Its hard-anodized aluminium body with an S45C hard-chrome 25 mm rod saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into heavy clamping fixtures and press gantries where a full-length body cannot. This model has no magnet fitted; order the -S code if you need CMSE / DMSE switch sensing. The ACP100X150B is discontinued - the current-production direct is ACE100X150, so confirm ISO 21287 mounting dimensions before swapping.
Airtac ACP Compact Cylinder ACP100X150B Technical Specifications
| Model | Airtac ACP Compact Cylinder ACP100X150B |
|---|---|
| Series | ACP DIN compact cylinder (discontinued) |
| Replacement | ACE100X150B |
| Bore size | Ø100 mm |
| Stroke | 150 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACE100X150B (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | 5154 N |
| Max (@1.0 MPa) | 801 kgf | |
The ACE100X150B produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac ACP Compact Cylinder ACP100X150B
| ACP | DIN compact cylinder (double-acting, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACP Compact Cylinder ACP100X150B Is Used
Heavy fixture clamping
The 3927 N push at 0.5 MPa clamps large steel weldments in machining fixtures, with the 150 mm stroke clearing the load for loading.
Small press and forming stations
With 5497.8 N available at 0.7 MPa, this bore handles light pressing, staking and swaging on assembly lines at 30-500 mm/s.
Pallet gate and stopper actuation
In warehouse conveyor systems, the short body drives lift-and-locate gates where a full-length profile cylinder would not fit.
Replacing the Airtac ACP Compact Cylinder ACP100X150B with the ACE100X150B
At this force class, 3927 N push at 0.5 MPa covers heavy clamping and pressing; if your load needs under 2513 N, the 80 mm bore is enough, and if you need more than 5497.8 N at 0.7 MPa there is no larger ACP bore, so look at a larger ACE. Stroke 150 mm sits inside the 300 mm maximum standard stroke for bore 100, so no made-to-order stroke is needed. Remember a plain ACP drifts when air is lost - add a rod lock or pilot check valve for a held load. FA/FB flange, LB foot, CA/CB clevis, CR, SDB and FTC mountings bolt to the same face, and the -S magnet enables CMSE / DMSE switches. Since ACP is discontinued, order ACE100X150 as the current replacement and verify ISO 21287 dimensions.
Replacement checklist
- ✓ Current-production ACE → ACE100X150B
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACP Compact Cylinder ACP100X150B FAQ
At 0.5 MPa: 3927 N push and 3681.6 N pull. At 0.7 MPa: 5497.8 N push and 5154.2 N pull. Theoretical maximum is 800.9 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, port 1/4" PT, rod 25 mm with male thread (B code).
No - the ACP series is discontinued. The current-production replacement is ACE100X150 (swap the P for an E), an ISO 21287 compact cylinder in the same bore, stroke and force class with a matching mounting family. Confirm the ISO 21287 mounting dimensions before swapping, since the ACP was built to a DIN standard. If you need position sensing, order the -S magnet option with CMSE / DMSE switches.
